Mitutoyo - 543-282b Absolute Digimatic Indicator, Id-c Type, In/metric, #4-48

US $340

Brooklyn, New York, United States
Jun 9th

Open on mobile:
QR code

Mitutoyo - 543-282B Absolute Digimatic Indicator, ID-C Type, in/Metric, #4-48 The Mitutoyo 543-282B Absolute Digimatic electronic indicator gauge, ID-C series, is for measuring short, linear distances in mechanical engineering, machining, and manufacturing applications in harsh environments. It has a measurement range of 0 to 0.5" (0 to 12.7mm), a resolution of 0.00005" (0.001mm), and an accuracy of + or - 0.00012". The LCD screen displays measurements in inches and metric units. The indicator has a go/no-go display that lights green or red, respectively, when upper and/or lower tolerances have been set. This unit has a 3/8" diameter stem and a #4-48 UNF contact point thread mount. It has a flat back for stem mounting or plate mounting on the rear of the indicator. An Absolute electrostatic capacitance-type linear encoder helps prevent overspeed errors and ensure accurate measurements. This model is Ingress Protection certified IP54 for protection against dust and water. Additional functions for this indicator include remote control, max/min/runout value holding, origin set, preset, zero set, counting direction switching, and alerts for low voltage, counting value composition, overflow, and tolerance limit setting errors. The measuring force is 2.0 Newtons (N) or less. This unit comes with a built-in power cord with exposed wires at the end for wiring into a device such as a programmable logic controller (PLC) (sold separately) for power and communications. This gauge can output the judgment signal using the included 4m cable.SpecificationsRange0 to 0.5" (0 to 12.7mm)Resolution0.00005" (0.001mm)Accuracy+ or - 0.00012"Measuring force2.0N or lessStem#4-48 UNF contact point thread mount with 3/8" diameter stemFaceLCD displays in both inches and metric units, green or red lighting displays go/no-go judgment, with flat backData input/outputSignal input (remote control) and judgment signal outputDimensions127.85 x 60.5 x 36.1mm (H x W x D)Weight335gStandardsIP54Power sourceBuilt-in power cordH is height, the vertical distance from the lowest to highest point with stem at rest W is width, the horizontal distance from left to right D is depth, the horizontal distance from front to back.Dial indicators are also called dial gauges, probe, and electronic indicators. These precision instruments measure small linear distances and object sizes. The dial magnifies the measurement so that it can be easily read by the human eye. Frequently used in manufacturing, laboratories, and other industrial or mechanical fields, dial indicators are used anywhere a small measurement must be found and recorded or transferred, such as checking the variation in tolerance of a workpiece. Standard dial indicators measure the displacement along the axis of the indicator. Dial test indicators are very similar to dial indicators, except that the axis of measurement is perpendicular to the axis of the indicator. Dial and dial test indicators can be analog, with a mechanical dial, or electronic, with a digital display. Some electronic models transfer the data electronically to a computer for recording and potential manipulation.Mitutoyo manufactures precision measuring tools, metrology equipment, and related systems. The company, founded in Tokyo in 1934, formed Mitutoyo America Corporation in 1963 with headquarters in Aurora, IL.What's in the Box?Mitutoyo 543-282B indicator gauge Product Features: Electronic indicator measures 0 to 0.5" (0 to 12.7mm) with 0.00005" (0.001mm) resolution and + or - 0.00012" accuracy, for measuring short, linear distances in mechanical engineering, machining, and manufacturing applications in harsh environments LCD screen displays measurements in inches and metric units, and go/no-go display lights red or green when upper and lower tolerances have been set Stem has 3/8" diameter and a #4-48 UNF contact point thread mount, and unit has a flat back for stem/plate mounting Absolute electrostatic capacitance-type linear encoder for accurate measurements Ingress Protection certified IP54 for protection against dust and water Dimensions (in): 3.20 X 6.10 X 6.10 Important Information: We offer discounted rates for bulk purchases, please inquire. We combine shipping, please note that certain items cannot be combined. In case you don&rsquot see the shipping rate displayed, please feel free to contact us for a shipping quote. _________________________________________________________________ International Shipping: Ø if you need a super fast international shipping please contact us Ø We do combine shipping, the more you buy the lower the shipping cost. Ø International shipping may be subject to a longer handling time. Ø Estimated time in transit is still just an estimate, in some cases items are subject to an extended time in transit due to custom delays, extended inspections in your country or lack of efficiency of the postal service. Ø USPS Standard mail or Priority mail are not guaranteed to be trackable, the service which is guaranteed to be trackable is USPS EXPRESS mail. Ø Most items are shipped with USPS. However, if you prefer a different shipping method, please notify us prior to purchase. Ø We cannot be responsible for time in transit, custom fees or for custom delays. Ø All international items are insured. Thank you for Looking!
