N.i.b. Von Duprin Ps914!!! No Reserve!!!!

US $41

Rockport, Massachusetts, United States
Jan 30th

Open on mobile:
QR code

Description Von Duprin PS914 Power Supply, 24VDC-4A. Von Duprin’s power supply and option boards were designed to meet the specific requirements of electrified fire exit devices. Installation is simplified by utilizing a flat mounting design and polarized locking connectors for option boards. This new design eliminates the need for racks and side connectors. The flat mounting of the option boards also provides for easier access to the terminal blocks for connection of electrified devices (such as electrified panic devices, strikes, card readers, etc.). Common to the line of PS900 Series power supplies is a constant output rating at both 12v and 24v settings, universal 120 VAC to 240 VAC input, and polarized option board connectors. New fire alarm interface board mounting allows outputs to be configured as switched (power cut) or unswitched (power continues) when signal is provided. Von Duprin Power Supply Catalog Features and Benefits - 4A @ 12/24 VDC output, field selectable with jumper - Designed with high in rush current for powering electrified panic devices - Universal 120 - 240 VAC input - Low voltage DC, regulated and filtered - Electronic power limiting foldback circuit for AC current overload protection - Two polarized connectors for distribution boards - Fused primary input - AC status monitor - isolated SPDT contacts - AC input and DC output LED status indicators - Cover mounted AC input indication - Hinged cover with lock down screws - High voltage protective cover PS914 Power Supply Specifications - Input voltage: 120/240 VAC, 50/60 Hz, universal input - Output voltage: 4A @ 12 or 24 VDC, Field selectable with jumper, Switching supply, 5% regulation, 360mVpp max ripple - Enclosure: Grey/baked enamel, 14" x 12" x 4" (H x W x D), Eight 1/2 ” x 3/4 ” knockouts, Hinged cover with lock down screws - Operating temperature: 32° - 120°F (0° - 49°C) - Certifications: UL 294, RoHS, FCC Part 15, Class 2 - Option board compatibility: 900-BB: Battery backup, 900-BAT: Backup battery pack, 900-BBK: Battery backup kit (backup board and battery pack), 900-FA: Fire alarm (must be installed on distribution boards), 900-2RS*: 2 Relay EL panic device control board, 900-4R*: 4 Relay output board, 900-4RL*: 4 Relay logic board, 900-8F*: Fused 8 zone distribution board, 900-8P*: PTC 8 zone distribution board - AC primary fuse size: 6.3A, 250v, 5 x 20mm SLOW-BLOW - Battery fuse size: 7.5A 32v ATO blade style - DC output protection: Overload protection - current limited foldback circuit - Indicators: LED indicators: AC input (visible on outside of enclosure), DC output, Isolated SPDT contacts to monitor AC power status -AC input termination: 3 position terminal block with protective cover, Wire capacity: 10 AWG max. - DC output termination: 2 position terminal block, Wire capacity: 12 AWG max. -Distribution board connectors: 2 -Fire alarm board connector: No -Keylock: Optional Available Options - Emergency Interface/Fire Alarm Relay (FA) - Must be installed on distribution boards - Key lock available for added security (KL) - Battery backup - 2 relay EL panic device control board - 2 relay QEL panic device control board - 4 relay distribution board - 4 relay distribution board with logic - Field configurable for: -Time delay function -Auto operator -Security interlock - 8 fused output distribution board - 8 PTC output distribution board *All PS900 Series power supplies and option boards have been tested and certified t
