National Instruments Scb-68 Pin Noise Rejecting Shielded I/o Connector Block

US $1100

Phoenix, Arizona, United States
Jun 21st

Open on mobile:
QR code

National Instruments SCB-68 Pin Noise Rejectinng Shielded I/O Connector Block Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from National Instruments and may vary slightly due to upgrades, options, or revisions this unit may or may not have. These units are used. The Unit's Serial Number Tag Reads: Model Number: SCB-68 Part Number: 182469-01B or 01C Revision: B4 Serial Number: BA4C6B CE Marked: Yes Link to the Manual: National Instruments SCB-68 Connector Block Manual Link to the Manual #2: National Instruments SCB-68 Connector Block Manual #2 Key Features: Shielded I/O connector block for use with 68-pin X, M, E, B, S, and R series DAQ devices Screw terminals for easy I/O connections or for use with CA-1000 2 general-purpose breadboard areas Onboard cold-junction compensation sensor for low-cost thermocouple measurements General Specifications: Number of Screw Terminals: 68, all I/O signals are available at screw terminals Temperature Sensor: Accuracy: ±1.0°C over a 0 to 110°C range Output: 10 mV/°C Power Requirement Specifications: Power Consumption at +5 VDC, ±5%: Typical: 1 mA with no signal conditioning installed Maximum: 800 mA from host computer Physical Specifications: Box Dimensions: 18.1 cm x 15.2 cm x 4.5 cm (7.1" x 6.0" x 1.8") Weight: 828 g (1 lb 13 oz) I/O Connector: One 68-pin male SCSI connector Screw Terminals: 68 Wire Gauge: 14-30 AWG Torque: 0.5-0.6 Nm (4.43-5.31 lb.in.) Maximum Working Voltage Specifications: Channel-to-Earth: 30 Vrms / 42 Vpk / 60 VDC Channel-to-Channel: 30 Vrms / 42 Vpk / 60 VDC Environmental Specifications: Operating Temperature: 0 to 70°C Storage Temperature: -20 to 70°C Relative Humidity: 5 to 90%, non-condensing Maximum Altitude: 2,000 m Pollution Degree (Indoor Use Only): 2 For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Inside Picture 5 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $5.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 09/25/14 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
