Neoden, Cheap, Stable, Smt Machine, Pnp Machine,tm220a, Solder Printer,0402-5050

US $16000

??, ???, China
Jun 9th

Open on mobile:
QR code

Neoden Desktop Pick and Place machine TM220A TM220A is Neoden's first generation pick and place machine with 17 patents and CE certificate. This automatic PnP machines is suitable for small batch production, laboratory research and development, product sample trials, LED SMT processing and other similar processes. This machine earned a reputation for excellent performance, high accuracy, stability and competitive price. You can rely on our machine to consistently produce medium volume and stable quality products. Specifications of TM220A and TM240A for your better comparison. Product Characteristics: * Laser sighted, easy for online programming * Vacuum detection, automatically dispose and make up if picking fail or pick misaligned * Dual pick and place head design helps increase output, 360-degree orientation * Noise reduction, Dual built-in mute type pumps (cost saving and room saving, no need to prepare additional pump) * Standard 8G SD card, mass storage of CSV working file * LCD, Touch screen interface input/output, easy operation (Chinese/English), user friendly design * Integrated Automatic Feeders (can be customized, cost saving, no need to buy extra mobile feeders), Automatic Nylon Spool (automatically and conveniently peel away nylon film) * Works with four different sizes high-precision nozzles * Can mount 0402, 0603, 0805, 1206, 1812, 2010, 2512, SOT-23, LED (3528, 5050, etc.), SOT89, SOP-8, SOP-14, SOP-16, SOT-223, SOT-252 and IC components (IC size under 16*16mm, PIN foot less than 100, fine-pitch above 0.5mm, the height of component less than 3mm) with required precision. * No vision system, the self-developed Laser positioning principle is quite effective for this type of machine. * Build-in software operating system, support Online programming: could easily do online program if you don’t have PCB Circuit diagram, with the assistance from laser positioner. No need to attach to a separate computer. * Easy programming, only takes 5mins: use Protel tool to extract the PCB circuit coordinate file, and use the format transformation tool we provided to you to transform the file format, and then copy it to the SD card, insert to the machine, then you could use the file directly. * Standard packaging ensures safe transportation. * Small and light bodyt: simple installation, convenient transportation. * Working power 100W: Environmental and energy saving. Standard Accessories: 1) Pick and Place Machine TM220A: 1 2) 4 types of nozzle: Totally 6 (XS—2, S—2, M—1, L—1). 3) 8G SD Card: 1 4) Card reader: 1 5) Nozzle disassembly tool: 1set 6) Adjustment tool for Nylon Spool Wheel: 1 7) Nozzle cleaning tool: 1 set 8) User manual: 1 9) Video training course: 1 set 10) PCB Coordinate file transformation tool: 1

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Neoden
MPN	TM220A/small
Model	TM220A/small
Country/Region of Manufacture	China
UPC	Does not apply
