New Ampro Cm2-sxi-q-73 Circuit Board

US $350.00

Tewksbury, Massachusetts, United States
Jan 29th

Open on mobile:
QR code

AMPRO CM2-SXI-Q-73 Core Module 3XI PCI/AT compatible PC/104 cpu module C M 2 - S Xi The CoreModule/3SXi provides cost-effective 386SX processing power and PC/AT compatibility in a compact, preconfigured subsystem module. Within just 14 square inches of space, the CoreModule/3SXi includes the equivalent functions of a PC/AT motherboard plus several additional expansion cards. Cost-sensitive embedded applications that formerly required chip-based custom designs can now benefit from an off-the-shelf module powered by a 25 MHz 386SX-compatible CPU, along with hardware and software standards like PC/AT and MS-DOS compatibility. C o re M o d u l e™/ 3 S Xi • Low Cost PC/AT-compatible PC/104™ compliant CPU module The CoreModule/3SXi is designed to meet the demands of embedded systems through its extremely compact design, low power consumption, +5V-only operation, wide operating temperature range, and high reliability. CONFIGURATION FLEXIBILITY The CoreModule/3SXi can be used as a macrocomponent, plugged into a proprietary application board, or it can be combined with PC/104-compatible expansion products to form compact, highly integrated control subsystems. Multiple modules can be stacked together without the cost and space penalties of additional mounting hardware. POWER CONNECTOR RS485 CONNECTOR FLOPPY INTERFACE SERIAL PORT 2 IDE INTERFACE ONBOARD DRAM EXPANSION DRAM MODULE CONNECTOR BYTEWIDE SOCKET OEM FLASH UTILITY CONNECTOR INTEGRATED 386SX PROCESSOR/CHIPSET PC/104 BUS SUPER I/O CONTROLLER PARALLEL PORT SERIAL PORT 1 386SX-compatible, 25 MHz internal clock rate • 2 or 4 Mbytes directly surface-mounted. Additional 4 Mbytes via plug-in DRAM module • 7 DMA channels (8237 equivalent) • 14 interrupt channels (8259 equivalent) • 3 programmable counter/timers (8254 equivalent) • PC/AT-compatible keyboard port • Speaker port with 0.1 watt drive • CMOS RAM (MC146818 equivalent); requires external 3.0 - 3.6V battery (Tadiran TL-5242/W or equivalent) • Award BIOS with Ampro embedded-PC enhancements • Two RS232 serial ports with full handshaking • One port is jumper-configurable for RS232 or RS485 • Both ports implemented using 16C550 equivalent with 16 byte data FIFOs • EPP/ECP compatible bidirectional parallel printer port • Support for 1 or 2 IDE hard disk drives • Low profile 44 pin compact 2mm connector • Supports 1 or 2 drives • Usable with 32K - 1 Mbyte EPROMs, 32K - 512K Flash EPROMs, 32K - 512K SRAMs, or 32K - 512K NOVRAMs • SRAM backup using off-board battery • Configurable as 64K, or 128 Kbyte window, addressed in the range D0000-EFFFFh • Usable with DiskOnChip2000™ read/write Flash SSD device • Onboard 1 Mbyte OEM Flash • 960 Kbytes available for OEM use (balance used by system BIOS) • Configurable as 64 Kbyte window, addressed in the range D0000-DFFFFh or E0000-EFFFFh • SSD 5.31 Support Software converts into an in-system programmable, read-only SSD devices • OEM Flash TFFS software converts into a full read/write SSD drive (not usable simultaneously with DiskOnChip2000™) • 2K bit configuration EEPROM, with 512 bits for OEM use • Supports battery-free boot capability • Utilizes real-time clock alarm function • Timeout triggers hardware reset or non-maskable interrupt • 3.6 x 3.8 x 0.9 in. (90 x 96 x 23mm); PC/104 compliant form factor (Includes stackthrough pins. Please refer to PC/104 specification for stacking and other dimensions.) • 16-bit PC/104 bus • Requirements (typical 25 MHz with 4 Mbytes RAM): +5V ±5% — 500 mA active / 160 mA sleep • Operating temperature: 0° to 70° C standard; –40° to +85° C extended (special order) • 5% to 95% relative humidity, non-condensing • Storage temperature: –55° to +85° C • Weight: 3.0 oz. (85 gm) THE M E C H A N I C A L ADDITIONAL ONBOARD FUNCTIONS •

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	AMPRO
MPN	CM2-SXI-Q-73
Model	CM2
Country/Region of Manufacture	United States
