New Celerity Intelliflow Ii H2 200sccm Mass Flow Controller Mfc Asm 54-125572a03

US $1900

Phoenix, Arizona, United States
Jun 21st

Open on mobile:
QR code

NEW Celerity IntelliFlow II (IN2) H2 200 sccm Mass Flow Controller (MFC), ASM PN: 54-106858A61 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Brooks Instrument/Mykrolis/Celerity and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This part is new, old stock from ASM. The package may have been opened and re-sealed to recalibrate the units so that ASM could ship them when a customer ordered them. The calibration is past due however. ASM Information: Part Number: 54-125572A03 Description: FC-INTFLW IIA-H2-200 SCCM-AI-NO Link to the Datasheet: Celerity IN2 Series Mass Flow Controller Datasheet Link to the Manual: Celerity IN2 Series Mass Flow Controller Manual Part Number Breakdown: Product: Mass Flow Controller - Normally Open (NO) Valve Materials: Stainless steel body with Hastelloy sensor Flow Range (N2): 173 - 438 sccm Fittings: 124 mm 4VCR, FC2900 Base (< 30 slm) Electrical Interface and Connections: 0 - 5 VDC, 9-pin Sub-D; "T" Option Flow Firmware Revision: 23 (According to box label description) Special Options: Standard Configuration (According to description Peformance Specifications: Full Scale Flow (N2 Equivalent): < or = to 30 slm (this unit is setup for 173 - 438 sccm) Turndown Ratio: 50:1 Response/Setting Time: 1 sec. (typical) Accuracy (Analog Mode)*: ±(0.25% SP + 0.50% FS) Accuracy (Digital Mode)*: ±(0.25% SP + 0.35% FS) Linearity: ±0.50% full scale maximum Repeatability: ±0.15% full scale maximum Ambient Temperature Coefficient: ±0.05% full scale/0°C maximum (zero and span) Normally Closed. ±0.10% full scale/°C maximum (zero and span) Normally Open. Inlet Pressure Coefficient: ±0.007% full scale/psi (0.10% bar) with autozero disabled Electrical Specifications: Input Voltage Requirement: Analog: ±15 VDC (±20%) DeviceNet: +11-25 VDC Power Supply Sensitivity: ±0.05% full scale maximum Power Consumption: Analog: 3 watts maximum DeviceNet: 5 watts maximum Analog I/O Signal: 0-5 VDC Digital Communication: RS-485 standard (DeviceNet Optional) Mechanical Specifications: Control Valve Type: Normally closed or normally open solenoid valve, diaphragm isolated (This is configured to be Normally Open) Materials Exposed to Process Gas: 316L VIM/VAR, stainless steel, sapphire, ruby, Hasteloy C-22, Inconel Leak Integrity (External): < 1 x 10-10 atm.cc/sec. Valve Leakthrough1: Normally Closed < 1% full scale Surface Finish: 5 µin Ra Environmental Specifications: Operating Temperature Range (Ambient and Gas): 0-50°C Humidity: 10 to 95% RH non-condensing Maximum Overrange Pressure: 140 psig (9.5 bar) Differential Pressure: 7-40 psid (< or = to 11 slm), 15-40 psid (11 - 30 slm) Notes: *: Accuracy reflects factory calibration gas and conditions. 1: Valve leakthrough for normally open devices < -2% full scale. For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $20.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 03/13/12
