Wt3-200 Wire Terminal Tester, 200 Lbf

US $2,349.00

Forest Hills, New York, United States
Jan 30th

Open on mobile:
QR code

Product DescriptionThe WT3-200 wire terminal pull tester is designed to measure the pull-off force of wire and tube terminations. An ergonomic lever allows for easy application of up to 200 lbF (1000 N) of pull force. Adjustable wire terminal grip contains multiple slots for wire diameters up to AWG 3 (0.25 in [6.3 mm]). A large, backlit graphic LCD displays easy-to-read values, including real-time force, peak force, programmable pass/fail limits, units of measurement, and more. Data can be transferred to a PC or other data collector via USB, RS-232, Mitutoyo (Digimatic), or analog outputs. An analog load bar is shown on the display for graphical representation of applied force. On-board data storage for up to 1,000 readings is included, as are statistical calculations and output to a PC. Unique automatic output / data storage / zeroing upon sample break helps automate testing processes. Product Features Measures real-time and peak force values Ergonomic lever operation produces 200 lbF [1000 N] USB, RS-232, Mitutoyo (Digimatic), and analog outputs Automatic output / data storage / zeroing upon sample break helps automate testing processes 1,000-point data memory with statistics and outputs Password protection prevents unauthorized changes Programmable set point indicators and outputs for pass/fail determination High-speed 7,000 Hz sampling rate accurately captures peak force values Configurable audio alarms and key tones Mounting holes for bench mounting Product Specifications Accuracy ±0.2% of full scale Wire diameter range AWG30 - AWG 3 [0.03 - 0.25 in (0.8 - 6.3 mm)] Minimum sample length 7.50 in [191.0 mm], excluding termination Maximum sample elongation 1.15 in [29.2 mm] Power AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. Battery Life Backlight on; up to 7 hours of continuous use Backlight off; up to 24 hours of continuous use Sampling rate 7,000 Hz Outputs USB / RS-232; Configurable up to 115,200 baud. Mitutoyo (Digimatic); Serial BCD suitable for all Mitutoyo SPC-compatible Devices. Analog; ±1 VCD, ±0.25% of full scale at capacity. Configurable Settings Digital filters, outputs, automatic shutoff, default settings, passwords, key tones, audio alarms, backlight, calibration Safe overload 150% of full scale (display shows "OVER" at 110% and above) Weight 16.0 lb [7.3 kg] Warranty 3 years (see individual statement for further details)

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	WT3-200
Country of Manufacture	United States
Manufacturer	ABQ Industrial
