New Electroswitch 103303a 103 Series 30 Amp

US $160

Westerville, Ohio, United States
May 30th

Open on mobile:
QR code

location:6Q5 NSN NSN 5930010919570 Information: Click on Cage Code, Part Number, Company Name, or End Item Identification to search for similar inventory available for auction through Government Liquidation. Cage Code: Part Number: Company Name: 82121 103303A ELECTRO SWITCH CORP DBA ELECTROSWITCH MRC: Requirement Name: Requirement: AAJD THREAD CLASS 2B SINGLE MOUNTING FACILITY ABFE III HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION MOISTURE RESISTANT ABHP OVERALL LENGTH 4.844 INCHES NOMINAL ABKW OVERALL HEIGHT 4.125 INCHES MAXIMUM ABMK OVERALL WIDTH 4.125 INCHES MAXIMUM ABNB FIRST FLAT LENGTH 0.875 INCHES NOMINAL SINGLE ACTUATOR ABNC FLAT HEIGHT 0.344 INCHES NOMINAL SINGLE ACTUATOR ABWV SHAFT DIAMETER 0.375 INCHES NOMINAL SINGLE ACTUATOR ABXF SHAFT LENGTH 1.125 INCHES NOMINAL SINGLE ACTUATOR AFBH INDIVIDUAL SECTION QUANTITY 3 AFCQ III KNOB MANUFACTURER CODE 82121 AFCY III KNOB MANUFACTURER PART NUMBER A AFDS LONGEST HORIZONTAL DISTANCE BETWEEN MOUNTING CENTE 2.281 INCHES NOMINAL SINGLE MOUNTING FACILITY AFDV LONGEST VERTICAL DISTANCE BETWEEN MOUNTING CENTERS 2.281 INCHES NOMINAL SINGLE MOUNTING FACILITY AJZE SWITCH CONTACT BASIC DESIGN NONPILE-UP SYMMETRICAL AKPX POLE QUANTITY 1 EACH SECTION REAR AKPY THROW QUANTITY 3 EACH SECTION REAR AXGY MOUNTING METHOD THREADED HOLE SINGLE MOUNTING FACILITY CBBL FEATURES PROVIDED ACTUATOR KNOB CMLP THREAD QUANTITY PER INCH 20 SINGLE MOUNTING FACILITY CQJX NOMINAL THREAD SIZE 0.250 INCHES SINGLE MOUNTING FACILITY CQMK CONTACT VOLTAGE RATING IN VOLTS 600.0 AC AT SEA LEVEL CQMK CONTACT VOLTAGE RATING IN VOLTS 250.0 HIGHEST DC VOLTAGE RATING AT SEA LEVEL CQMK CONTACT VOLTAGE RATING IN VOLTS 125.0 LOWEST DC VOLTAGE RATING AT SEA LEVEL CQYJ MOUNTING FACILITY PATTERN FOUR POSITION RECTANGULAR SINGLE MOUNTING FACILITY CRJH SWITCH ACTUATOR INDEXING POSITION QUANTITY 4 SINGLE ACTUATOR CRSJ SHAFT TYPE ROUND, FLATTED, THREADED HOLE SINGLE ACTUATOR CSCF TERMINAL TYPE TAB W/SCREW CSHW CONTACT SWITCHING ACTION BREAKS BEFORE MAKES EACH SECTION REAR CSLC SWITCH ACTUATOR POSITIONING INCREMENT 90.0 DEGREES SINGLE ACTUATOR CTDN SWITCH ACTUATOR STOP DEVICE TYPE FIXED STOP SINGLE ACTUATOR CTHF CONTACT LOAD CURRENT RATING 40.0 AMPERES RESISTIVE LOAD AC AT SEA LEVEL CTHF CONTACT LOAD CURRENT RATING 15.0 AMPERES RESISTIVE LOAD HIGHEST DC VOLTAGE RATING AT SEA LEVEL CTHF CONTACT LOAD CURRENT RATING 30.0 AMPERES RESISTIVE LOAD LOWEST DC VOLTAGE RATING AT SEA LEVEL STYL STYLE DESIGNATOR 1 TAP, CIRCUIT SELECTOR THSD THREAD SERIES DESIGNATOR UNC SINGLE MOUNTING FACILITY
