NEW OLD STOCK - FLUKE 196B SCOPEMETER HANDHELD OSCILLOSCOPE - 100MHz - FREE SHIP FREE SHIPPING IN THE CONTINENTAL U.S.A. ONLY WE SHIP WORLD WIDE E-MAIL US FOR PRICE QUOTE ------------------------------------- NEW OLD STOCK - FLUKE 196B SCOPEMETER HANDHELD OSCILLOSCOPE - 100MHz RETAILS NEW $2499.99 ----------------------------- STILL HAS PLASTIC LENS COVER TO PROTECT THE VIEWABLE SCREEN CONTENTS BC190/803 Battery Charger/Line Voltage Adapter BP190 NiMH Battery Pack Getting started booklet User manual (CD-ROM) TL75 Hard Point Test Lead Set VPS200-G Voltage Probe (200 MHz, 10:1), Grey VPS200-R Voltage Probe (200 MHz, 10:1), Red Features Dual-input – 200, 100 or 60 MHz bandwidth Up to 2.5 GS/s real-time sampling per input Connect-and-View™ automatic triggering and a full range of manual trigger modes Digital Persistence for analyzing complex dynamic waveforms like on an analog scope Fast display update rate for seeing dynamic behavior instantaneously Automatic capture and replay of 100 screens 27,500 points per input record length using ScopeRecord mode TrendPlot paperless chart recorder for trend analysis up to 22 days Up to 1000 V independently floating isolated inputs Waveform reference for visual comparisons and automatic pass/fail testing of waveforms Vpwm function for motor drive and frequency inverter applications. 1000 V CAT II and 600 V CAT III safety certified Four hours rechargeable NiMH battery pack A choice of bandwidth See what's really happening Easier identification of traces, everywhere See dynamic signal behavior instantaneously Advanced trigger modes Waveform Pass/Fail Testing Automatic capture and replay of 100 screens Use TrendPlot™ to help find intermittents, fast Deep memory for high-resolution ScopeRecord™ Analysis power Measure from mV to kV - fully isolated and safely! Many more new functions SCOPEMETER 100MHZ B/W SCC USA ScopeMeter 190B Series: Speed, performance and analysis power. For the more demanding applications, the ScopeMeter 190 Series high-performance oscilloscopes offer specifications usually found on top-end bench instruments. With up to 200 MHz bandwidth, 2.5 GS/s real-time sampling and a deep memory of 27,500 points per input they’re ideal for engineers who need the full capabilities of a high-performance oscilloscope in a handheld, battery powered instrument. See More, Fix More with Color With the high performance specifications usually found on bench oscilloscopes, plus the large high resolution color screen, the new Digital Persistence mode, and a much faster display update rate, the Color ScopeMeter Series brings a new dimension to working in the field. A choice of bandwidth The ScopeMeter 190C and 190B Series offer up to 200 MHz bandwidth for capturing high-frequency signals found in today’s state-of-the-art electronics. For less demanding applications, there are also 100 MHz and 60 MHz models. You still get the same advanced functionality without paying for bandwidth you don't need. See what's really happening With a maximum real-time sampling rate of 2.5 GS/s per input, you can see what really happens, with 400 ps resolution. Both inputs have their own digitizer, so you can simultaneously acquire two waveforms and analyze them with the highest resolution and detail. If an anomaly flashes by on the screen, just press the Replay button to see it again. And thanks to the wider screen, you will always see a 12 divisions time window - giving a far better overview of what's happening both before and after the trigger event! Easier identification of traces, everywhere The full-color display makes identification of individual waveforms easier, particularly when displaying large amplitude or multiple overlapping waveforms on screen. On-screen color labels, measurements and warnings are clearly linked to specific waveforms. The bright, high-contrast display allows for clear reading under varying light conditions. And still a 4-hour battery operation time is assured! See dynamic signal behavior instantaneously The Digital Persistence mode (Fluke 190C) helps to find anomalies and to analyze complex dynamic signals by showing the waveforms amplitude distribution over time. Digital Persistence uses multiple intensity levels and user selectable decay time - it's as if you're looking at the display of an analog, real time oscilloscope! The fast display update rate that's standard on all models reveals signal changes instantaneously, useful for instance when making adjustments to a system under test. Advanced trigger modes A wide choice of automatic and manual trigger modes gives you the flexibility to capture just about any signal you'll encounter. Connect-and-View™ triggering is ideal for fast and easy checking of multiple test-points. The manual modes include time delay, video and pulse width triggering. A fully isolated external trigger input is included for troubleshooting time relationships between two input signals synchronized to a third signal. Waveform Pass/Fail Testing "Waveform reference" allows an acquired trace to be stored and designated "reference trace" for visual comparisons, or it can be used as the reference for automatic "Pass/Fail" testing (190C). Up to 100 individually matching ("Pass") or non-matching ("Fail") waveforms can be stored in the replay memory, allowing you to monitor your system's behavior over a long period of time, without the need for you to be present! Automatic capture and replay of 100 screens Scope users know how frustrating it is to see an one-time anomaly flash by never to be seen again. Not with the ScopeMeter 190 Series! Now you can look back in time with a touch of the replay button. In normal use, the instrument continuously memorizes the last 100 screens. Each time a new screen is acquired, the oldest is discarded. At any moment, you can "freeze" the last 100 screens and scroll through picture-by-picture or replay as a "live" animation. Cursors can be used for further analysis. You can even use the advanced trigger capabilities to capture up to 100 specific events. Two sets of 100 captured screens with individual time stamps can be stored for later recall or download to a PC. Use TrendPlot™ to help find intermittents, fast The toughest faults to find are those that happen only once in a while - intermittents. They can be caused by bad connections, dust, dirt, corrosion or simply broken wiring or connectors. You may not be around to see it - Fluke's ScopeMeter will. In this "paperless recorder" mode, you can plot the minimum and maximum peak values and average over time - up to 22 days. The two inputs can plot any combination of volts, amps, temperature, frequency and phase - with time and date stamp - to help lead you to the cause of those faults quickly. Deep memory for high-resolution ScopeRecord™ The ScopeRecord memory stores 27,500 points per input or more, for high-resolution recording of events up to 48 hours, and captures fast intermittents and glitches as short as 50 ns. This continuous roll mode, for example, stores events like motion profiles, UPS, power supply and motor start-ups. All models also have a "Stop-on-Trigger" in the ScopeRecord mode. This allows the ScopeMeter to store waveform data until the instrument is triggered or until a repetitive trigger signal is interrupted. This way, the instrument will, for example, automatically recognize a power failure and store the waveform data preceding it. And with 100 x zoom, you can look at the smallest details, like individual power cycles. Two of these 27,500 point recordings can be stored for later analysis. Analysis power For analysis of waveforms, ScopeRecords and TrendPlot recordings, the ScopeMeter 190C and 190B features 30 automatic measurements, cursors, zoom and real-time clock. The analysis can be made directly or later when back in the office. Up to two recordings and 10 scope screens can be stored for analysis, print-out or download to a PC. Measure from mV to kV - fully isolated and safely! The ScopeMeter 190C and 190B series have three independently floating isolated inputs. While conventional oscilloscopes can only make measurements referenced to the line power ground, measurements on each of the Fluke ScopeMeter 190 series inputs can be referenced to a different "low" level. This enables measurements in mixed circuits having different ground references, and also eliminates the risk of accidental ground short circuits. All inputs are safety certified for measurements in 1000 V CAT II and 600 V CAT III environments. And the standard probes cover a wide application range from mV to kV, making the 190C and 190B ScopeMeter ideal for micro electronics to electrical applications. Many more new functions Variable gain on channel A helps you compare signals on the two inputs. The Vpwm measurement is for measuring the effective rms output voltage of variable speed motor drives and frequency inverters. The high-sensitivity setting of 2 mV/div allows for measurements on low-level signals, that are hard to make with the average oscilloscope. (Fluke 190C) For medical imaging diagnostics or high resolution video applications, an optional configuration is available with current over time (mAs), high-resolution video triggering (up to 2800 lines) and more. Bandwidth Fluke 199C, 199B: 200 MHz Fluke 196C, 196B: 100 MHz Fluke 192B: 60 MHz Max. real time sample rate Fluke 199C, 199B: 2.5 GS/s Fluke 196C, 196B: 1.0 GS/s Fluke 192B: 500 MS/s Display Fluke 19xC: 144 mm Full Color LCD Fluke 19xB: 144 mm Monochrome LCD Digital Persistence Fluke 19xC: Yes, gives analog oscilloscope like waveform decay (user selectable) Fluke 19xB: Persistence on/off Envelope mode Yes Waveform Compare Fluke 19xC: Visual Reference and Automatic ‘Pass / Fail’ testing Fluke 19xB: Visual Reference Max. record length … in Scope mode: 1200 points per input channel … in ScopeRecord mode: 27,000 points per input or more (5 ms/div…2 min/div.) Number of inputs 2 plus external / DMM input, all isolated from each other and from ground Number of digitizers 2 Independently floating isolated inputs Up to 1000 V between inputs, references and ground Input sensitivity Fluke 19xC: 2 mV/div. … 100 V/div. Fluke 19xB: 5 mV/div. … 100 V/div. Glitch capture Up to 3 ns using Pulse Width triggering; 50 ns peak detect at 5 ms/div. to 1 min/div. Timebase range in Scope mode Fluke 199C, 199B, 196C, 196B: 5 ns/div to 2 min/div Fluke 192B: 10 ns/div to 2 min/div. Trigger types Connect-and-View®, Free Run, Single Shot, Edge, Delay, Video Frame, Video line, Selectable pulse width and External Scope Measurements 7 cursors measurements, 30 automatic measurements Waveform Mathematics A + B, A – B, A x B, A versus B (X-Y-mode, giving Lissajous diagrams) Scope-Record Trigger modes Start on Trigger, Stop on Trigger Capture last 100 screens Automatic, with Replay capability Dual input TrendPlot Yes, with Cursors and Zoom Memory for screens and set-ups 10 screens with set-up; 5 more memories are made available upon registration of theScopeMeter Memory for recordings Two, each can store 100 scope screens, a ScopeRecord or a TrendPlot True RMS multimeter 5000 counts, Volts, Amps, Ohms, Continuity, Diode, Temp Safety certified (EN61010-1) 1000 V CAT II / 600 V CAT III (instrument and included accessories) Battery (installed) 4 hr Ni-MH BP190 Line power Adapter / battery-charger included Size 25.6 x 16.9 x 6.4 cm (10.1 x 6.7 x 2.5 inch) Weight 2 kg PC and Printer interface Using optional Optically Isolated RS-232 adapter / cable Certain images/photos incorporated into this template are the royalty free property of idlelimey: license Creative Commons 3.0.
