New Qualiflow Afc 260 H2 300 Sccm Mass Flow Controller Mfc Asm Pn: 54-117817a39

US $3500

Phoenix, Arizona, United States
Jun 17th

Open on mobile:
QR code

NEW Qualiflow AFC 260 H2 300 sccm Mass Flow Controller (MFC), ASM PN: 54-117817A39 Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Qualiflow and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This part is new, old stock from ASM. The calibration is probably past due. ASM Information: Part Number: 54-117817A39 The Unit's Paperwork Reads: Model Number: AFC-260 Range: 300 sccm Gas: H2 Inlet Pressure: 30 PSI Outlet Pressure: ATM Positioning: VIU Link to the Datasheet: Qualiflow AFC-260 & AFM-360 Series Mass Flow Controller & Meter Datasheet Link to the Manual: Qualiflow AFC-260 & AFC-261 Mass Flow Controller Manual Features: Compatible with other MFC Economic design, simple construction Compatible with MODULINE via optional adapting connector (from factory) Outstanding records throughout various industries Possibility to regulate with external readout Specifications: Flow Range (equivalent N2): 10 sccm to 5 slm (this unit is setup for 300 sccm) Control Range: 2 - 100% F.S. Valve Type: Thermal Valve Rest Position: Normally Open only Accuracy: ±1% of F.S. Linearity: ±0.5% of F.S. Repeatability: ±0.3% of F.S. Sensibility to Mounting Position: ±0.1% of F.S. Step Response Time: ~6 sec. typical (SEMI E17-91) Operating Temperature: 5 ~ 40°C, non-condensing Temperature Coefficient: < 0.5% F.S./°C Maximum Inlet Pressure: 1 MPa (10 bar, 150 psi) Minimum Differential Pressure: 50 kPa (70 kPa with H2) Maximum Differential Pressure: 300 kPa (3 bar, 43 psi) Pressure Coefficient: < 0.1% F.S./105 Pa Wetted Materials: 316 L Stainless steel Leak Integrity: < 2.10-8 atm.scc/sec (He) Standard Seals: Viton, Neoprene (Not sure what seal this unit has.) Fittings: 1/4" VCR, Swagelok Weight: 0.5 Kg Input and Output Specifications: Mass Flow Meter: ±15 VDC, 50 mA Input and Output Signal: From 0 to 5 VDC Electrical Connector: Card edge For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $10.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 01/28/14 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
