New S2000uv,nir Spectrometer

US $1,500.00

Hangzhou, ???, China
Mar 8th

Open on mobile:
QR code

S2000-UV is a spectrometer made by Surwit Technology Inc., This spectrometer is designed for spectrum analysis in LED, energy-saving lamps, fluorescent lamps and many other fields. Lamp Technical Parameters spectral output range 200 nm to 1100 nm Power 40 w AC input voltage 150 v ~ 250v Operating temperature 5 ~ 35 °C Preheat time 8 ~ 10 minutes Optical fiber interface SMA905 The deuterium lamp (D2) spectral output range 200 nm to 400 nm Power 30 w service life 1000 hours Stability 1 x 10-3 AU Drift 0.25% / h Starting vol tage 1 kv voltage Excitation frequency 250 KHZ Tungsten lamp (W) spectral output range 350 nm to 1100 nm Power 10 w Life 2000 hours SpectraAnalysis have multiple spectra line display,multiple spectra dispose,snapshot,buffer spectra, peak-searching/valley-searching,FWHM, coordinate convert,spectra recording functions. It mainly consist by Control Window ?Spectra Window and Spectra List Window. Control window used to change settings of USB data collection;Spectra Window display the current spectra or file spectra collect from USB and open spectra recording file;Spectra setting window mainly control the display style of spactra line. Text label, mouse right button spectra line move, prompt bar and mouse prompt in spectra graphic make the operation more convenient, and get the spectra line information easily. It can contract with Microsoft ,export the spectra data asExcel and Word files. The program will save the spectra as *.ssp files,double click or move file into window can open the spectra graphic. Color Analysis The function use the international authority full spectrum method (Without V ( lambda ) error correction ) to analysis spectral power distribution, chromaticity coordinates, correlated color temperature, color deviation , color tolerance, peak wavelength, color rendering index ( Ra)of LED, energy-saving light source and fluorescent powder . Wavelength range is 380nm ~ 780nm. The corresponding electrical equipment can measure voltage, current, power source, power factor. The analysis and control of products are all realized by computer software, software operation is simple, and with a strong light source test and data analysis and processing function, measurement data can be exported to Excel, txt and SSP ( spectral file ) for a variety of file formats, very convenient for calculation and analysis. Spectra Data Software can be download at http://www.surwit.com/yArticInfo/104.htm Example for application Objects reflectivity measurement System configuration A. Spectrometer S2000-UV or S2000-UV/NIR B. Software SpectraPro V3.2 C. Adjustable halogen light source or Deuterium/Tungsten light source DH02 D. Reflectivity measurement accessories E. Standard whiteboard F: Y type optical fiber root (SMA905 interface) C and E can be bought from us according to clients requirement.
