New Sharp Lt021mdo Laser Diode 10mw, 780nm Infrared Ir 9mm

US $24.95

  • Peoria, Arizona, United States
  • Jan 30th
  INFRARED LASER DIODE The Sharp LT021MDO is a GaAlAs laser diode with VSIS chip structure. It has a built in photo diode for monitoring the laser output for use in automatic power control (APC) circuits. The common case pin is laser diode cathode and photo diode cathode. Included is a factory spec sheet and individual specifications. SPECIFICATIONS: Output Power: 10 mW typical, 15 mW maximum. Wavelength: 780 nm typical, 795 nm maximum. INFRARED Operating Voltage: 1.8 Volts typical Threshold Current: 45 mA typical Operating Current: 75 mA typical Monitor Current: 3.0 mA typical. Operating Temperature: -10 to 60 deg.C. Package: TO-9, 9 mm diameter base, Low cap type. Note: Due to the sensitive nature of laser diodes, there is no warranty or exchanges on these items.           These are new old stock diodes, individually characterized in factory containers.  Please see our other auctions for similar items. Meredith Instruments 9880 W. Peoria Ave. Peoria, AZ 85345 See our ME page for contact info.     Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
