Newport Spectra Physics Oclaro 16 Watt 808nm Laser Diode Dpss Bpc808-16 Burns

US $40.00

Oakland, California, United States
Jan 30th

Open on mobile:
QR code

16 Watt Diode These diodes were obtained from another eBay seller. He said these diodes are from Oclaro q/a engineering and were from pre - production test runs of this 16 watt diode type. Actual operating specifications will be with in 15% of the Specification Chart below. The 16 watt diode specs are in the second column shaded green. Every diode will be tested for power and wavelength prior to shipping to you. Description The Oclaro BPC808-16 30% fill factor laser diode baron passive cooler series has been designed to provide the high output power and high reliability required for both solid-state laser pumping and direct applications.. The laser diode bars are mounted on an expansion matched submount onto a Cu block package providing very high reliability in CW and pulsed (1-Hz type)applications) applications. Applications § Solid state laser pumping § Direct applications such as material processing § Printing § Medical Features § Mounted 10mm wide laser diode bar § Passive 1" x 1" Cu block cooler § 30% Fill Factor (150µm emitter / 500µm pitch) § 16W operating power § Highly reliable single quantum well structure § Telecom grade AuSn mounting technology § RoHS Compliant BPC808-16 Wavelength2 808 ±3 nm Typical Spectral Width (FWHM) <3 nm Maximum Spectral Width (FWHM) 5 nm Output Power Po3 16 W Operating Current Iop4 22 A Maximum Operating Current Iop 30 A Threshold Current Ith5 7.1 A Maximum Threshold Current Ith 9.0 A Number of Emitters 19 Typical Conversion Efficiency 35% @ Iop Typical Beam Divergence 90% of rated power within 14° cone angle (0.12 NA) Electrical Maximum Operating Voltage 2.2 V Maximum Reverse Voltage 3 V Maximum Negative Current 25 µA 1. Centroid wavelength @ 25°C thermistor temperature 2. Guaranteed minimum optical output power 3. Typical operating current required to achieve Po 4. Typical threshold current Typical wavelength temperature coefficient: 0.20-0.30 nm/°C

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“All diodes are tested to be within 15% of manufacturer's specification. See below. Diodes not meeting specification are not sold and scrapped”
