Ni Pxi-7841r R Series Multifunction Rio With Virtex-5 Lx30 Fpga Daq Adc Dac

US $1,400.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PXI-7841RR Series Multifunction RIO With Virtex-5 LX30 FPGA New, unused item, only PXI card in original pack8 analog inputs, independent sampling rates up to 200 kHz, 16-bit resolution, ±10 V 8 analog outputs, independent update rates up to 1 MHz, 16-bit resolution, ±10 V 96 digital lines configurable as inputs, outputs, counters, or custom logic at rates up to 40 MHz Virtex-5 LX30 FPGA programmable with the LabVIEW FPGA Module 3 DMA channels for high-speed data streaming MFG price: $3.100 More information The NI PXI-7841R multifunction reconfigurable I/O (RIO) module features a user-programmable FPGA chip for onboard processing and flexible I/O operation. You configure all analog and digital functionality using NI LabVIEW graphical block diagrams and the LabVIEW FPGA Module. Your block diagram executes in the hardware, giving you direct, immediate control over all I/O signals to deliver high-performance capabilities such as the following: -Complete control over the synchronization and timing of all signals and operations -Custom onboard decision making that executes with hardware-timed speed and reliability -Digital lines individually configurable as inputs, outputs, counter/timers, PWM, flexible encoder inputs, or specialized communication protocols NI R Series multifunction RIO devices feature a dedicated analog-to-digital converter (ADC) per channel for independent timing and triggering. This offers specialized functionality such as multirate sampling and individual channel triggering, which are outside the capabilities of typical DAQ hardware. Common examples include custom discrete and analog control, sensor simulation, rapid prototyping, hardware-in-the-loop (HIL) test, digital protocol emulation, and other applications that require precise timing and control. Required Software This product requires the LabVIEW FPGA Module Version 8.5.1 or later and NI-RIO Version 2.4 or later driver software. Virtex-5 FPGA The Virtex-5 FPGA architecture is optimized to execute faster and more efficiently using single-cycle Timed Loops in LabVIEW FPGA. This means you can optimize more LabVIEW FPGA code to fit within Virtex-5 FPGAs and execute more operations per clock cycle. General Product Family Multifunction DAQ Measurement Type Filters Frequency LVDT Quadrature encoder RVDT Voltage Form Factor PXI / PXI Express PXI Bus Type PXI Hybrid Compatible Operating System / Target FPGA Real-Time Windows Module Width 1 RoHS Compliant Yes Analog Input Single-Ended Channels 8 Differential Channels 8 Analog Input Resolution 16 bits Maximum Voltage Range Range -10 V - 10 V Accuracy 3.97 mV Sensitivity 0.305 mV Minimum Voltage Range Range -10 V - 10 V Accuracy 3.97 mV Sensitivity 0.305 mV Number of Ranges 1 Simultaneous Sampling Yes On-Board Memory 192 kB Signal Conditioning Deglitch filter Low-pass filtering Analog Output Number of Channels 8 Resolution 16 bits Maximum Voltage Range Range -10 V - 10 V Accuracy 5.88 mV Sensitivity 0.305 mV Minimum Voltage Range Range -10 V - 10 V Accuracy 5.88 mV Sensitivity 0.305 mV Update Rate 1 MS / s Current Drive Single 2.5 mA Current Drive All 20 mA Digital I / O Bidirectional Channels 96 Input-Only Channels 0 Output-Only Channels 0 Timing Hardware Maximum Clock Rate 40 MHz Logic Levels 3.3 V 5 V LVTTL TTL Programmable Input Filters Yes Supports Programmable Power-Up States? Yes Digital Input Input Type Sinking Sourcing Maximum Voltage Range 0 V - 5 V Digital Output Output Type Sinking Sourcing Current Drive Single 4 mA Current Drive All 384 mA Maximum Voltage Range 0 V - 3.3 V Counters / Timers Watchdog Timer Yes Counters 96 Number of DMA Channels 3 Buffered Operations Yes Debouncing / Glitch Removal Yes Max Source Frequency 40 MHz Pulse Generation Yes Size 64 bits Timebase Stability 100 ppm Logic Levels 3.3 V 5 V LVTTL TTL Timing / Triggering / Synchronization Triggering Analog Digital Synchronization Bus(RTSI) Yes Physical Specifications Length 16 cm Width 10 cm I / O Connector 68-pin VHDCI female

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PXI-7841R
