Ni Pxi-7842r R Series Multifunction Rio With Virtex-5 Lx50 Fpga, Daq Adc Dac

US $1,600.00

Kossice, Slovakia
Jan 29th

Open on mobile:
QR code

NI PXI-7842RR Series Multifunction RIO With Virtex-5 LX50 FPGA New, unused item, only PXI card in original pack8 analog inputs, independent sampling rates up to 200 kHz, 16-bit resolution, ±10 V 8 analog outputs, independent update rates up to 1 MHz, 16-bit resolution, ±10 V 96 digital lines configurable as inputs, outputs, counters, or custom logic at rates up to 40 MHz Virtex-5 LX50 FPGA programmable with the LabVIEW FPGA Module 3 DMA channels for high-speed data streaming MFG price: $3.900 More information The NI PXI-7842R multifunction reconfigurable I/O (RIO) module features a user-programmable FPGA chip for onboard processing and flexible I/O operation. You configure all analog and digital functionality using NI LabVIEW graphical block diagrams and the LabVIEW FPGA Module. Your block diagram executes in the hardware, giving you direct, immediate control over all I/O signals to deliver high-performance capabilities such as the following: -Complete control over the synchronization and timing of all signals and operations -Custom onboard decision making that executes with hardware-timed speed and reliability -Digital lines individually configurable as inputs, outputs, counter/timers, PWM, flexible encoder inputs, or specialized communication protocols NI R Series multifunction RIO devices feature a dedicated analog-to-digital converter (ADC) per channel for independent timing and triggering. This offers specialized functionality such as multirate sampling and individual channel triggering, which are outside the capabilities of typical DAQ hardware. Common examples include custom discrete and analog control, sensor simulation, rapid prototyping, hardware-in-the-loop (HIL) test, digital protocol emulation, and other applications that require precise timing and control. Specifications Summary General Product Name PXI-7842R Product Family Multifunction Data Acquisition Form Factor PXI Platform PXI Bus Type PXI Hybrid Compatible Part Number 780338-01 Operating System/Target Real-Time , FPGA , Windows LabVIEW RT Support Yes Power Requirement for +3.3V Rail 1.484 A Power Requirement for +5V Rail 291 mA Power Requirement for +12V Rail 500 mA Power Requirement for -12V Rail 250 mA Slot Two Module No Module Width 1 MXI Compatible Yes DAQ Product Family R Series Measurement Type Quadrature encoder , RVDT , Filters , Frequency , Voltage , LVDT RoHS Compliant Yes Signal Conditioning Low-pass filtering , Deglitch filter Analog Input Channels 8 Single-Ended Channels 8 Differential Channels 8 Resolution 16 bits Sample Rate 200 kS/s Max Voltage 10 V Maximum Voltage Range -10 V - 10 V Maximum Voltage Range Accuracy 3.97 mV Maximum Voltage Range Sensitivity 0.305 mV Minimum Voltage Range -10 V - 10 V Minimum Voltage Range Accuracy 3.97 mV Minimum Voltage Range Sensitivity 0.305 mV Number of Ranges 1 Simultaneous Sampling Yes On-Board Memory 192 kB Analog Output Channels 8 Resolution 16 bits Max Voltage 10 V Maximum Voltage Range -10 V - 10 V Maximum Voltage Range Accuracy 5.88 mV Maximum Voltage Range Sensitivity 0.305 mV Minimum Voltage Range -10 V - 10 V Minimum Voltage Range Accuracy 5.88 mV Minimum Voltage Range Sensitivity 0.305 mV Update Rate 1 MS/s Current Drive Single 2.5 mA Current Drive All 20 mA Digital I/O Bidirectional Channels 96 Input-Only Channels 0 Output-Only Channels 0 Timing Hardware Maximum Clock Rate 40 MHz Logic Levels TTL , 3.3 V , 5 V , LVTTL Input Current Flow Sinking , Sourcing Output Current Flow Sinking , Sourcing Programmable Input Filters Yes Supports Programmable Power-Up States? Yes Current Drive Single 4 mA Current Drive All 384 mA Watchdog Timer Yes Supports Handshaking I/O? Yes Supports Pattern I/O? Yes Maximum Input Range 0 V - 5 V Maximum Output Range 0 V - 3.3 V Counter/Timers Counters 96 Number of DMA Channels 3 Buffered Operations Yes Debouncing/Glitch Removal Yes GPS Synchronization No Maximum Range 0 V - 5 V Max Source Frequency 40 MHz Minimum Input Pulse Width 12.5 ns Pulse Generation Yes Resolution 64 bits Timebase Stability 100 ppm Logic Levels TTL , 3.3 V , 5 V , LVTTL Reconfigurable FPGA FPGA Type Virtex-5 LX50 Physical Specifications Length 16 cm Width 10 cm I/O Connector 68-pin VHDCI female Timing/Triggering/Synchronization Triggering Digital , Analog Synchronization Bus (RTSI) Yes

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	National Instruments
Country of Manufacture	Hungary
Model	NI PXI-7842R
