Nib Altronix Al602ulada Nac Power Extender

US $434

Monmouth Junction, New Jersey, United States
Jan 30th

Open on mobile:
QR code

THIS IS NEW IN BOX NEVER OPENED AL602ULADA are extremely cost effective voltage regulated remote NAC Power Extenders. They may be connected to any 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC) expansion (supports ADA requirements) and providing auxiliary power to support system accessories. Input: Power input 120VAC 60 Hz, 4 amp. Two (2) Class A, Style Z or two (2) Class B, Style W, X, Y FACP inputs. Two (2) NC dry contact trigger inputs. Output: 24VDC @ 6.5 amp max total alarm current. 2.5 amp max current per output. Separate 1.0 amp auxiliary output. Two (2) outputs may be paralleled for more power on an indicating circuit (see 02 Application Guide). Programmable supervised indicating circuit outputs: Four (4) Class B, Style W, X, Y or Two (2) Class A, Style Z or One (1) Class A, Style Z and Two (2) Class B, Style W, X, Y (see 02 Application Guide). Thermal and short circuit protection with auto reset. Battery Backup: Charging voltage is 26.2-26.4VDC. Built-in charger for sealed lead acid or gel type batteries. Automatic switchover to stand-by battery when AC Fails. Zero voltage drop when switching over to battery backup. Supervision: AC fail supervision (form "C" contact, 1 amp / 28VDC).Factory set for 30 seconds with optional 2.5 to 3 hour delay setting (field selectable). Instant local AC trouble reporting relay (form "C" contact, 1 amp / 28VDC). Battery presence and low battery supervision (form "C" contact, 1 amp / 28VDC). Visual Indicators: Input and output status LED indicators. Special Features: 2-wire horn/strobe Sync mode allows audible notification appliances (horns) to be silenced while visual notification appliances (strobes) continue to operate. Sync protocols include Potter/Amseco, Faraday, Gentex®, System Sensor®, and CooperWheelock®. Temporal Code 3, Steady Mode, Input to Output Follower Mode (maintains synchronization of notification appliances circuit). Compatible with 12VDC or 24VDC fire panels. Output loop supervision steered to input 1 or input 2. Signal circuit trouble memory (helps identify intermittent loop problems). Common trouble input and output for external trouble signals tie-in. Ground fault detection. Unit includes power supply, red enclosure, cam lock, and battery leads

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Altronix
Model	AL602ULADA
