FLX380-30x FlexTester3 High-Performance Micro OTDR FLX380-300 (1310/1550 - 41/38 dB) FLX380-302 (1310/1490/1550) and FLX380-303 (1310/1550/1625) AVAILABLE DISCOUNT PRICING UPON REQUEST ESales@TAMGE.com or call 207-221-3154 (WE TAKE TRADE-INS. IF YOU HAVE ANY EQUIPMENT YOU NO LONGER USE, TAKE IT OFF THE DUSTY SHELF AND TURN IT INTO A CASH TRADE-IN) This is the newest Noyes OTDR for the next generation. If you have been searching for this unit, you know it has such high demand that it is difficult to find. Light on weight and heavy on performance makes the FLX380 an OTDR of choice for years to come. FLX380 FlexTester PON-optimized Micro OTDR The NOYES FLX380 FlexTester is the world’s smallest, lightest, most complete single-mode fiber optic test set. It combines high-performance, PON-optimized, multi-wavelength OTDR/PON OTDR, OLS, OPM, VFL and PON Power Meter in a rugged, hand-held package. Features 3rd generation hand-held, all-in-one OTDR, OLS, OPM, VFL Patented in- or out-of-service testing from a single port 42/42 dB dynamic range @ 1310/1550 nm; test up to 1x128 PON Industry-leading 0.8/2.5/30 m event / attenuation / PON dead zones ServiceSafe™ live PON detection and OTDR test without service disruption Integrated OLS/OPM with Wave ID reduces test time 80% and eliminates setup errors Rugged, hand-held and lightweight (<1 kg) High-contrast display: clear and bright, even in direct sunlight Industry leading battery life: over 12 hours operation from a single charge It’s all about speed: with Instant On, you’re ready to test in <5 sec Applications Certify new FTTx PON or point-to-point fiber installations, including splice, splitter and connector loss and reflectance, end-to-end length, loss and optical return loss (ORL). Troubleshoot live FTTx PONs, including live PON detection and PON power measurements plus live PON OTDR testing at 1625 or 1650 nm. Complete multi-wavelength end-to-end insertion loss tests faster and eliminate setup errors using AFL’s Wave ID loss test feature. Generate stable optical source signals (CW, Wave ID or fiber-identifying tones) using the integrated Optical Laser Source. Trace fibers or locate fiber bends or breaks using the VFL (visible red laser). The FLX380 FlexTester offers an unmatched combination of optical test functions, ease-of-use, portability and value, including: 41 dB dynamic range OTDR Best-in-class event, attenuation, and PON dead zones AFL’s unique ServiceSafe™ Live PON OTDR Fast, error-free loss-testing using Wave ID synchronization. Over 12 hours continuous testing without battery replacement or recharge Integrated 50 m launch fiber. The handheld FLX380 FlexTester is offered in three models to best suit your application requirements: The NOYES FLX380 FlexTester3 is the world’s smallest, lightest, most complete single mode fiber optic test set. It combines high-performance, multi-wavelength OTDR / PON OTDR, OLS, OPM, VFL and PON Power Meter in a rugged, hand-held package. With 42 dB dynamic range, best-in-class event, attenuation, and PON dead zones, macrobend and splitter detection, launch quality check, plus AFL’s unique ServiceSafe and Wave ID features, the FLX380 FlexTester3 Series offers an unmatched combination of optical test functions, ease-of-use, portability, and value. FlexTester3 Series is offered in four models to best suit your application requirements: FLX380-304: Verify both in-service (live) and out-of-service FTTx networks from a single port. Includes 1310/1550/1650 nm live PON OTDR with integrated PON Power Meter. 41/41/38 dB. FLX380-303: Similar to FLX380-304, but with 1625 nm filtered Live PON OTDR, instead of 1650 nm. 41/41/38 dB. FLX380-302: Complete out-of-service testing at all FTTx PON wavelengths (1310/1490/1550 nm). 41/38/41 dB. FLX380-300: Lowest cost, high-performance, all-in-one 1310/1550 nm OTDR for out-of-service installation testing or troubleshooting on both FTTx PON and point-to-point fiber optic networks. 42/42 dB. (This is the item that is being auctioned off. Call or email for other model prices) All models include integrated VFL plus Wave ID source and power meter. Over 1000 OTDR test results (Telcordia SR-4731 .SOR file format) may be saved in the FLX380’s internal 4GB memory. Stored OTDR and OPM results may be transferred to PC via USB cable or wirelessly via Bluetooth®. Windows® compatible TRM® 2.0 Basic Test Results Manager software is included for OTDR and OPM results viewing, analysis, and professional report generation. The FLX380 FlexTester user interface provides modes suitable for both novice and expert users. It features a top-down menu structure which is both easy to learn and a pleasure to use. User interface software supports over a dozen languages including English, Chinese (Simplified and Traditional), French, German, Italian, Japanese, Korean, Portuguese, Polish, Russian and Spanish. Over 1000 OTDR test results may be saved in industry-standard .SOR file format. Stored OTDR and OPM results may be transferred to PC via USB port for viewing, analysis, and professional report generation using the included Windows® compatible TRM® 2.0 Basic Test Results Manager software. Advanced analysis and reporting capabilities, including micro-/macro-bend detection and bi-directional trace averaging, are available by upgrading to TRM 2.0 Advanced. FLX380 FlexTester Configuration Option In FTTx PONs, it is possible for one user to lose service while other subscribers served by the same OLT continue to remain in service. Attempting to troubleshoot a faulty optical distribution and drop fiber connection from the out-of-service subscriber’s location using a 1310 or 1550 nm OTDR, would disrupt service to remaining users. AFL’s patented ServiceSafe feature alerts the OTDR user to the presence of live traffic and prevents the initiation of service-disrupting OTDR tests at 1310 or 1550 nm. FLX380-303 and -304 models additionally measure downstream power levels at 1490 and/or 1550 nm, and allow the user to initiate an OTDR test using a non-disruptive 1625 or 1650 nm wavelength. To eliminate unnecessary connector wear and tear, 1625/1650 nm live PON OTDR testing and PON power measurements are performed through the same optical port used for 1310/1550 OTDR testing Create Professional Test Reports using TRM® 2.0 Stored OTDR and/or OPM results can be uploaded via USB to a PC, then viewed and analyzed using TRM 2.0 Basic Test Results Manager software included with each FLX380 FlexTester3. With TRM, users can generate professional acceptance test reports conforming to industry guidelines. TRM allows users to create customized cover pages with their company logo along with results pages showing dual wavelength traces, event tables, event map, and loss results for each fiber. A report generation Wizard makes custom report generation fast and easy. TRM also supports OTDR trace analysis providing batch editing features, event add, modify, or delete, trace compare, and advanced event analysis capabilities. Upgrade to TRM 2.0 Advanced to add bi-directional trace averaging. 3 ESales@TAMGE.com 207-221-3154 We rent and 'lease to own'. We take trade-ins too. Visit our Noyes Store - www.TamgeStore.com Warranty: This brand new unit comes with a full 1 year Noyes factory . 72 Hour delivery available to job site Call 207-221-3154 about new customer - free domestic shipping www.TamgeStore.com
