Olimex PIC-IO microchip 18 pin pic Development board for PIC16F628, GBP 14.95 – Picture 0
Olimex PIC-IO microchip 18 pin pic Development board for PIC16F628, GBP 14.95 – Picture 0

Olimex Pic-io Microchip 18 Pin Pic Development Board For Pic16f628

GBP 14.95

  • Northampton, United Kingdom
  • Mar 29th
Open on mobile:
QR code
FEATURES ICSP/ICD connector for programming with PIC-MCP-USB, PIC-MCP or PIC-PG1, PIC-PG2, PIC-PG3, PIC-PG4 and debugging with PIC-ICD2, PIC-ICD2-POCKET, PIC-ICD2-TINY(* for the PICs with ICD support) Power plug-in jack for +12VDC power supply Voltage regulator +5V, 78L05 and filtering capacitors Status LED connected to RB5 Quartz crystal oscillator circuit 20Mhz DIL18 microcontroller socket RS232 DB9 female connector RS232 interface circuit with Tx, Rx signals 4 optocoupler isolated inputs with screw terminals Input status LEDs 4 relay outputs with 10A/250VAC contacts with screw terminals Output status LEDs FR-4, 1.5 mm (0,062"), green soldermask, white silkscreen component print Dimensions 100x80 mm (3,9x3,15") DOCUMENTS PIC-IO.pdf - PIC-IO user's manual revision C PIC-IO tutorial (English) PIC-IO tutorial (Spanish) PIC-IO dimensions HARDWARE PIC-IO schematic PIC ICSP connector SOFTWARE PIC-IO control of the outputs and inputs via RS232 (C source and HEX) PIC-IO RS232 send and receive demo code (C source and HEX) PIC-IO Blinking LED (C source and HEX) PIC-IO tutorial software Powered by eBay Turbo Lister Business seller information Olimex Ltd Contact details Jason Moore Sweetacres The Knoll, Grendon Northampton Northamptonshire NN7 1JG United Kingdom Phone:01933|666989 Email:ebay@olimex.co.uk Trade Registration Number: 7280533 Value Added Tax Number: UK 991828568 Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 14 days You pay return shipping
