Ortec 416A Gate and Delay Generator, US $299.99 – Picture 0

Ortec 416A Gate and Delay Generator, US $299.99 – Picture 1

Ortec 416a Gate And Delay Generator

US $299.99

Tucson, Arizona, United States
Jan 29th

Open on mobile:
QR code

The ORTEC 416A Gate and Delay Generator is part of a Minibin detector suite of modules that allow precise and accurate analysis of pulses from high-energy detectors. The ORTEC 416A Gate and Delay Generator accepts either polarity of input logic pulse, provides a delay of up to 110µs, and furnishes an output logic pulse with selectable amplitude, polarity, and width. The combination of functions provided by this module satisfies various logic requirements such as gating multichannel analyzers and alignment of coincidence timing between two channels using dissimilar pulse-shaping modes. Auxiliary outputs include a Delay Period with a width equal to the time, and a NIM-standard Fast-Negative Delayed Marker pulse. Excellent time stability allows application in systems that require nanosecond time precision. This Model 416A has only been used for a few hours on the test bench and is in wonderful original condition. Provides adjustment of the delay, width, polarity, and amplitude of gating pulses Positive or negative polarity input pulse Time delay from 0.1 to 110 µs Output pulse width from 0.4 to 4 µs Excellent time delay stability Specifications PERFORMANCE DELAY NONLINEARITY = ±2%. DELAY TEMPERATURE INSTABILITY = ±0.03% of adjusted Delay per °C. DELAY GENERATOR DEAD TIME Adjusted Delay plus 200 ns on 1.1-µs range, 300 ns on 11-µs range, and 1 µs on 110-µs range. OUTPUT GENERATOR DEAD TIME Adjusted Width plus 0.2 µs. DELAY JITTER <+0.02% of selected range. CONTROLS DELAY 10-turn locking potentiometer with direct-reading duo-dial for continuous adjustment within the range selected by the locking 3-position toggle switch: 1.1 µs Selects the range of 0.1 to 1.1 µs for the Delay potentiometer. 11 µs Selects a 1 to 11 µs range. 110 µs Selects a 10 to 110 µs range .AMPLITUDE Front-panel screwdriver control, permits the output pulse amplitude to be adjusted within the range of 2 to 10 V, both polarities (i.e., +2 to +10 V and –2 to –10 V). WIDTH Front-panel screwdriver control permits the width of output pulses to be adjusted within the range of 400 ns to 4 µs. INPUTS POS Front- and rear-panel BNC connectors; +2 V pulse minimum, 12 V maximum; 100-ns minimum width, dc-coupled; impedance 1000 Ohms. NEG Front-panel BNC connector accepts NIM-standard fast negative logic pulses; –250 mV pulse minimum; 5 ns minimum width, dc-coupled; impedance 50 Ohms OUTPUTS DELAYED OUT, POS/ NEG Front- and rear- panel BNC connectors, with test points, provide simultaneous output pulses with identical characteristics except for opposite polarity; impedance = 10 Ohms. DELAYED PERIOD Rear-panel BNC connector, with test point, provides positive pulse width equal to the adjusted Delay; amplitude +5 V; rise time ?50 ns; impedance 50 Ohms. DLY'D MARKER Front-panel BNC connector, with test point, provides NIM-standard fast negative logic pulse at the end of delay time. Amplitude, –0.6 V into 50 Ohm ?load; rise time =10 ns; width = 25 ns; impedance =10 Ohms. ELECTRICAL AND MECHANICAL POWER REQUIRED The Model 416A derives its power from a standard NIM bin/power supply. The power required is +24 V, 60 mA; –24 V, 60 mA; +12 V, 85 mA; and –12 V, 85 mA. WEIGHT Net 1.3 kg (2.8 lb). Shipping 2.2 kg (4.8 lb). DIMENSIONS NIM-standard single-width module 3.43 X 22.13 cm (1.35 X 8.714 in.) per DOE/ER-0457T.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Ortec
Country/Region of Manufacture	United States
