Pancake Shape Induction Coil 45x65mm W/ Magnet Centralization Induction Heaters

US $69.00

  • Edison, New Jersey, United States
  • Jan 30th
Open on mobile:
QR code
Oval pancake shape induction coil with magnet centralization for our IH series induction heaters. Good for small parts or surface heating. Specifications  Surface length  2 1/2 inches  Surface width  1 3/4 inches  Coil length (away from machine)  10 inches  Copper tubing diameter (OD)  5 mm  Coil style  Oval shape, single-tubing, 3-turn  Magnet  Magnet in the center  Surface  Flat mica  Connector  Copper nuts with 9/16" flare threading INDUCTION COIL DESIGN It is within the induction coil that the varying magnetic field required for induction heating is developed through the flow of alternating current. So coil design is one of the most important aspects of the overall system. A well-designed coil provides the proper heating pattern for your part and maximizes the efficiency of the induction heating power supply, while still allowing easy insertion and removal of the part. Induction coils are normally made of copper tubing - an extremely good conductor of heat and electricity - with a diameter of 1/8" to 3/16"; larger copper coil assemblies are made for applications such as strip metal heating and pipe heating. Induction coils are usually cooled by circulating water, and are most often custom-made to fit the shape and size of the part to be heated. So coils can have single or multiple turns; have a helical, round or square shape; or be designed as internal (part inside coil) or external (part adjacent to coil). There is a proportional relationship between the amount of current flow and distance between the coil and part. Placing the part close to the coil increases the flow of current and the amount of heat induced in the part. This relationship is referred to as the coupling efficiency of the coil.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Across International
Model IHOC-2.5-1.75
