Pci Development Kit Cyclone Ii Edition Altera Pci Kit W/cyclone Ii Ep2c35n

US $950.00

San Marcos, California, United States
Jan 29th

Open on mobile:
QR code

DK-PCI-2C35N - NEW CONDITION IN ORIGINAL BOX - EVERYTHING EXCEPT BOTTOM LEFT CORNER PICTURE (SCREWS) BOARD BAG WAS OPENED ONCE BY TEST ENGINEER AS YOU CAN SEE IN PICTURES OTHER CABLES , ETC. ARE UNOPENED Altera's PCI Development Kit, Cyclone® II Edition provides a flexible, low-cost FPGA development platform in a PCI short card form factor. With a universal (3.3-V and 5-V) PCI edge connector, the PCI Development Kit, Cyclone II Edition plugs into any standard PCI or PCI-X slot. The kit includes both a hardware reference design and Windows software drivers to accelerate development. Users can perform transactions between the PCI interface and DDR2 memory within minutes of opening the box. The kit can be used as a development platform for 32-bit and 64-bit PCI, PCI-X, DDR2 SDRAM, and Altera Megafunction Partners Program (AMPPSM) partner intellectual property (IP) cores. The PCI Development Kit, Cyclone II Edition features: Cyclone II PCI Development Board (see Figure 1)Cyclone II EP2C35F672 FPGA Short-form universal PCI (3.3 or 5.0 V) card32-bit or 64-bit PCI per the PCI Local Bus Specification Revision 2.3 at 33 or 66 MHz 100 MHz PCI-X Revision 2.0 mode 1 MemoryTwo 64 Mbyte DDR2 SDRAM devices FPGA device configurationSwitch-selectable on power-up, choose one of two serial configuration devices (EPCS64 devices). One device contains the pre-loaded factory default design, and the other device is for user-programming. Configuration data is downloaded via the USB-Blaster™ download cable. Flexible clocking optionsSocketed 100-MHz high-speed clock oscillator SMA connector clock input PCI edge connector clock input Switches and indicatorsFour user-definable push-button switches Eight-position user-definable dual in-line package (DIP) switch Eight user-definable LEDs Flexible power optionsPCI connector External power supply PCI Development Kit, Cyclone II Edition CD-ROMPCI-to-DDR2 Reference Design Cyclone II PCI Development Kit Application & Drivers PLD Applications PCI-X CORE CD-ROMPLD Applications PCI-X function for OpenCore® evaluation Reference designs&applications targeted to the Cyclone II PCI development board Quartus® II design software, including the SOPC Builder system development tool Windows platform only Jungo WinDriver Development Toolkit Cables&accessoriesUSB Blaster download cable Power cable Complete documentation

Condition	New other (see details) : A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“OPEN BOX”
