Phoenix Uslkg2.5 N Ground Modular Terminal Block,box Of (50) - New

US $39.99

Westerville, Ohio, United States
Jun 9th

Open on mobile:
QR code

Ground modular terminal block, Connection method: Screw connection, Number of positions: 1, Cross section: 0.2 mm? - 4 mm?, AWG: 24 - 12, Width: 6.2 mm, Color: green-yellow, Mounting type: NS 35/7,5, NS 35/15, NS 32 New in Box. Feel free to use best offer for reasonable offers General Number of levels 1 Number of connections 2 Color green-yellow Insulating material PA Inflammability class according to UL 94 V2 Rated surge voltage 6 kV Pollution degree 3 Surge voltage category III Insulating material group I Connection in acc. with standard IEC 60947-7-2 Open side panel nein Number of positions 1 Back to top Dimensions Width 6.2 mm Length 42.5 mm Height NS 35/7,5 42 mm Height NS 35/15 49.5 mm Height NS 32 47 mm Back to top Connection data Note Please observe the current carrying capacity of the DIN rails. Connection method Screw connection Connection in acc. with standard IEC 60947-7-2 Conductor cross section solid min. 0.2 mm? Conductor cross section solid max. 4 mm? Conductor cross section AWG min. 24 Conductor cross section AWG max. 12 Conductor cross section flexible min. 0.2 mm? Conductor cross section flexible max. 2.5 mm? Min. AWG conductor cross section, flexible 24 Max. AWG conductor cross section, flexible 14 Conductor cross section flexible, with ferrule without plastic sleeve min. 0.25 mm? Conductor cross section flexible, with ferrule without plastic sleeve max. 1.5 mm? Conductor cross section flexible, with ferrule with plastic sleeve min. 0.25 mm? Conductor cross section flexible, with ferrule with plastic sleeve max. 1.5 mm? 2 conductors with same cross section, solid min. 0.2 mm? 2 conductors with same cross section, solid max. 1.5 mm? 2 conductors with same cross section, stranded min. 0.2 mm? 2 conductors with same cross section, stranded max. 1.5 mm? 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, min. 0.5 mm? 2 conductors with same cross section, stranded, TWIN ferrules with plastic sleeve, max. 1.5 mm? 2 conductors with same cross section, stranded, ferrules without plastic sleeve, min. 0.25 mm? 2 conductors with same cross section, stranded, ferrules without plastic sleeve, max. 1.5 mm? Connection in acc. with standard UL Conductor cross section AWG min. 30 Conductor cross section AWG max. 12 Stripping length 7 mm Screw thread M3 Tightening torque, min 0.6 Nm Tightening torque max 0.8 Nm Back to top Classifications eCl@ss eCl@ss 4.0 27141118 eCl@ss 4.1 27141118 eCl@ss 5.0 27141118 eCl@ss 5.1 27141118 eCl@ss 6.0 27141141 eCl@ss 7.0 27141141 eCl@ss 8.0 27141141 Back to top ETIM ETIM 2.0 EC000901 ETIM 3.0 EC000901 ETIM 4.0 EC000901 ETIM 5.0 EC000901 Back to top UNSPSC UNSPSC 6.01 30211811 UNSPSC 7.0901 39121410 UNSPSC 11 39121410 UNSPSC 12.01 39121410 UNSPSC 13.2 39121410

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Pheonix Contact
Model	USLKG 2.5N
