PLASMA CAM Cutter Grates CNC X and Y Slats - Read Description, US $10.00 – Picture 0
PLASMA CAM Cutter Grates CNC X and Y Slats - Read Description, US $10.00 – Picture 0

Plasma Cam Cutter Grates Cnc X And Y Slats - Read Description

US $10.00

  • Wauseon, Ohio, United States
  • Jan 30th
Open on mobile:
QR code
Included in this auction are the plasma cam files needed to cut your own replacement grid slats for your 5' x 5' or 5' x 10' Plasma Cam Machine. If you have a Plasma Cam machine and purchase your replacement grid slats from PC this is for you!   A 5x5 machine uses the same slat for either direction and uses 20 pcs. A 5x10 machine uses 20 X direction and 20 Y direction slats.   These files allow to cut your own grate slats and save some money. I save almost $800.00 each time I cut another set for myself. These program files are designed to have the same points and end stop locations just like PC and come in the .pcm format. Each slat has 22 points (11 on the top and bottom). If you want the version with 62 point (31 on either side),  just include a note in your email. We also can provide these files for other bed sizes just email us. It is recommended to cut a few test pieces to adjust your offset to make sure your slots are the correct width. And that they mate. Once purchase has been complete the file will be emailed to your address. If you have any questions please feel free to email me.

Directions
