Pololu G2 High Power Motor Driver 13a, 6.5v-40v- 24v13

US $31.45

Swanton, Vermont, United States
Aug 19th

Open on mobile:
QR code

Description Operating voltage: 6.5 V to 40 V (absolute maximum) Output current: 13 A continuous Inputs compatible with 1.8 V, 3.3 V, and 5 V logic PWM operation up to 100 kHz The Pololu G2 High Power Motor Driver 13A, 6.5V-40V- 24v13 enables bidirectional control of one high-power DC brushed motor. The small 1.3″ × 0.8″ board supports a wide 6.5 V to 40 V voltage range and is efficient enough to deliver a continuous 13 A without a heat sink. Additional features of this second-generation (G2) driver include reverse-voltage protection along with basic current sensing and current limiting functionality. Features: Current sense output proportional to motor current (approx. 40 mV/A; only active while H-bridge is driving) Active current limiting (chopping) with default threshold of 30 A (can be adjusted lower) Reverse-voltage protection Undervoltage shutdown Short circuit protection Specifications Motor channels: 1 Minimum operating voltage: 6.5 V Maximum operating voltage: 40 V Continuous output current per channel: 13 A Current sense: 0.04 V/A Maximum PWM frequency: 100 kHz Minimum logic voltage: 1.8 V Maximum logic voltage: 5.5 V Reverse voltage protection: Y Identifying markings PCB dev codes: md31a Other PCB markings: 0J9257, blank white box Dimensions Size: 1.3" × 0.8" Weight: 3.3 g

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Pololu
Type	Pololu
MPN	2992
UPC	Does not apply
