Power Led Driver Supply Transformer Constant Current Cv

US $7.00

Registered Air Mail ( Worldwide ), China
Jan 29th

Open on mobile:
QR code

LED Power Driver Constant Voltage / Current Adjustable CC CV Specification: Module Properties: Non-isolated step-down constant current, constant voltage module (CC CV) charging module. Input Voltage: DC 7~35 V Output Voltage: DC 1.25~30 V ( adjustable, O/p Voltage < I/p Voltage by 2V ) Output Current: rated 3A, the largest 4A (more than 25W, enhance heat dissipation ) Constant Current Range: 0~4A (adjustable) The minimum voltage difference: 2V Fully Charged Current: = Constant current Value * ( 0.01 ~ 0.99 adjustable ). eg, Constant Current value: 3A, adjustable potentiometer: 0.1, Full charged current= 3A*0.1 =0.3A, When Charging current = 0.3A, Blue LED Lihgting. Default : 0.1 Output Power: natural cooling 25W, Max 30W Efficiency: 92% (up 92%, higher Voltage output, higher efficiency ) Output Ripple: 20M Bandwidth, Input 12V ; Output 5V 3A 0.06mV (MAX) Full Load temperature rise: 45 °C Potentiometer adjustment direction: clockwise (increase), counterclockwise (decrease) Indicator: Constant current RED LED, Charging RED LED, fully charged BLUE LED No-load Current: Typical 10mA Load Regulation: ± 1% Voltage Regulation rate: ± 0.5% Dynamic response speed: 5% 200uS Output Short-circuit Protection : Yes, Constant Current Input Reverse Protection: None Operating temperature: Industrial grade (-40 °C to +85 °C) (ambient temperature exceeds 40 degrees, lower power use, or to enhance heat dissipation) Size: 49 x 23.5 x 13.3 mm ( L*W*H ) Without heat sink & shell, Please visit my store. Application: High-power LED constant current driver Lithium battery charging ( Including ferroelectric ) 4V, 6V, 12V, 14V, 24V battery charging Ni-Cd Ni-MH batteries (battery) charging Solar panels, wind turbines DIY DC Power Supply . . . . . . Charge the battery, Use Mothod: Battery float voltage and charge current, and module input voltage. Constant Voltage adjustment potentiometer, Let Output Voltage = Float Voltage. Short-circuit current measurement with a multimeter, Let Output Current = Charge Current. Connected to the battery, try charging. LED constant current driver, Use Mothod: LED operating current and maximum working voltage. Constant Voltage adjustment potentiometer, Let Output Voltage = maximum working voltage. Short-circuit current measurement with a multimeter, Let Output Current = LED operating current. Connected LED. Packing Included 1 x DC CV / CC Power Supply Module Contact: Please use eBay message Contact us to Resolve Any Issues before Leaving Feedback or Open Dispute. We are in different time zones, reply your ebay message within 24 business hours. Shipping: Shipping time: usually 10 ~ 18 Business days, US, UK, DE, FR, CA, AU, NL, CH, SE, GR, BE ...... European Countries. But Italy, Spain, Russian, Israel, India, Indonesia, Philippines ...... need 14 ~ 25 Business days. Due to Local postal service & Customs, some countries take a little longer. We accepted International order. We ship to Worldwide. Ship to eBay address, please confirm your web address on eBay. Item will be shipped via Hong Kong Post or China Post, Use Registered Air Mail with tracking Number. Tracking number and track web site in item Notes to buyer, please go to see. Can not Combine postage. No sales tax and No handling fees. Payment: We prefer payment via PayPal, Moneybookers are also accepted. Payment must be made within 7 calendar days. Non-Paying bidders will be reported. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. Refund: Your satisfaction is our first priority. Defective product will be offered for a replacement or refund money. It is buyer's responsibility to contact us within 30 calendar days of receiving a defective product. Otherwise, no replacement or refund will be made. Buyer is responsible for shipping costs of delivery, item be returned in their original condition. When received, send you a replacement or refund within 24 business hours. Thank you for your bought, have a nice day! :).
