Programmed Test Systems X10 Frequency Synthesizer. 9-20 Mhz

US $7400

Irving, Texas, United States
Jan 29th

Open on mobile:
QR code

Programmed Test Sources PTS X10 Programmed Test Sources X10 X10S1T20 Frequency Synthesizer. 9-20 MHz. Front Panel or BCD, OCXO. 1 Hz Resolution. PTSX10 (PTS X10) Auction Includes the Following: 1) 14 Day Warranty Product Overview 9-20 MHz 1 Hz resolution with DDS phase-continuous switching fully programmable, BCD or front panel control. The PTS x10 transfers the accuracy and stability of a frequency standard (built-in or external) to any output frequency within the configured 10 MHz decade specified by the user at the time of order (e.g., 20-30 MHz, 30-40 MHz, etc.). Additional optional field-installable replacement modules allow easy and rapid reconfiguration to another selected decade. SPECIFICATIONS Frequency Range: specified 10 MHz decade, 0.1 - 100 MHz (0.1-10, 10-20,?, 90-100 MHz) Resolution: 1 Hz (optional, 0.1 Hz under remote-control only) Accuracy: same as frequency standard Control: manual by 10-position dial; remote by TTL-level parallel entry BCD or GPIB(optional) Switching Time (to within 0.1 radian at new frequency) 1 MHz digit non-phase-continuous: 5 µseconds phase-continuous: < 1 µsecond transient, 1 µsecond delay 100 KHz - 1 Hz digits: < 1 µsecond transient, 1 µsecond delay, phase-continuous Output Level: +3 to +13 dBm (1V max, 50 U ) Flatness: +0.25 dB Impedance: 50 U Control: manual by front panel control; remote by analog voltage Spurious (at full power output, +13 dBm) Outputs Discrete: -60 dBc Harmonics: -35 dBc Phase Noise: -70 dBc (0.5 Hz to 15 KHz) including effects of internal standard ? (1Hz): 10 Hz/ -110 dBc, 100 Hz/ -122 dBc, 1 KHz/ -132 dBc, 10 KHz/ -133 dBc, 100KHz/ -134 dBc Noise Floor: - 135 dBc/Hz Frequency Standard Internal: OCXO or TCXO 3x10-9/day 1x10-8/day ±1x10-8/0-50° C ±1x10-6/0-50° C 1x10-6/year 2x10-6/year External Drive: 10 MHz, 0.4 Vrms into 50 U ; 5 MHz, 0.5 Vrms into 50 U Aux. Output: 10.000 MHz, 0.4 Vrms into 50 U (Note: internal or external standard required for operation) General Operating Ambient: 0 - 55° C, 95% R.H. Power: 105 - 125V, 50 - 400 Hz, 30W (100, 220, 240V optional) Dimensions: 19 x 3.5 x 17.5 inches (relay rack or bench cabinet) MATsolutions “Buy with Assurance" Please Contact Lubin Raymond at MATsolutions for Questions regarding this listing at (877)621-1280. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	PTS
Model	X10
