Tektronix (tek) 671-0049-0x Acquisition Test Fixture For Scope & Logic Analyzer

US $21.50

  • Chapin, South Carolina, United States
  • Jan 29th
Open on mobile:
QR code
Quantity one, Tektronix (Tek) 671-0049-0x Acquisition Test Fixture for Oscilloscopes  & Logic Analyzers. Provides 24 logic signals, one glitch signal, and three clocks. Excellent tool for verifying operation of oscilloscope analog and digital inputs, logic analyzer inputs, and probes. There are two versions of this test board and they are substantially the same with the exception of: The 671-0049-00 version which was released by the scope folks. This version of the test board is not pictured. No silk screened line around the outer edge. Uses a switch to apply/remove power. Only a single row of square pins for the signals - the B column as seen in the fourth picture. The 671-0049-01 version which was released by the logic analyzer folks. This is the version of the test board that is pictured. Silk screened silver line around the outer edge. Uses a two-pin jumper to apply/remove power. Dual row of square pins for each output, signal/ground. The version of the board that you get will be chosen at random when they are pulled from the box. See the attached logic analyzer screen shots for pictures of the waveforms, glitch width (72.5ns), clock frequency (257.52kHz), and the length of the data pattern (66.49us). All of these come with a new battery (BR2330). I have seen these work using the current drawn from the logic analyzer probes to power the board (no battery). It gives you funky waveshapes but it is kind of cool to see it function without a battery. Check out my other items!
Condition Used :
An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes “In excellent condition.”
