Ps 8086 Trainer Kit User And Technical Reference Manual

US $399.00

MUMBAI, MAHARASHTRA, India
May 4th

Open on mobile:
QR code

8086 Trainer Kit user and Technical Reference Manual INTRODUCTION The PS-8086 board which demonstrates the capabilities of the 40-pin 8086 (various families) Sample programs are provided to demonstrate the unique features of the supported devices. The PS-8086 Kit comes with the following: PS-8086 Board Sample devices (INTEL 8086/NEC 8086) Cross cable (RS232) CD-ROM, which contains: - Sample programs - PS-8086 Board User manual Keyboard (101 keys) 8086 Board Overview The PS – 86A board is based on Intel 8086 Microprocessor, which operates at 6.144 MHz using the crystal of 18.432. The board can operate using the 101/104 PC keyboard supplied along with the trainer kit and 2 Line by 16-character LCD display or from the PC (using the Terminal Emulation Software). Microprocessor’s Address, Data and Control bus pins are brought to the 50 pin FRC connector.PS -86A is equipped with powerful software monitor in two-27C256 EPROM. The monitor supports Video terminal RS232C interface, local 101keyboard and LCD display. The board has 64KB CMOS static RAM (type 62256). PS -86A works on +9V DC. 8086 Specifications 8086 Microprocessor operating at 18.432 MHz 16KB powerful software monitor two 27C256 EPROM Three 16-bit programmable timers from 8253 48 programmable I/O lines from two nos. of 8255 Serial interface using 8251 50 pin FRC connector for system bus expansion 20 pin FRC connector for user interface from 8255 9 pin D type connectors for RS 232 interface Six different selectable baud rates from 150 to 9600 101 PC type keyboard for entering user address/data and for commands Built in line-by-line assemble and disassemble User friendly software monitor for loading and executing programs with break point facility System Description Hardware Processor Clock Frequncy 8086 operates at 18.432 MHz clock. Memory ORIGINAL IMAGES OF THE ACTUAL PRODUCT ARE UPLOADED, WHAT YOU SEE IS WHAT YOU GET SAME DAY SHIPPING AVAILABLE THROUGH DHL, UPS, ICCWORLD OR FEDEX WORLDWIDE Payment: Pay with your credit card through PayPal. Payment must be received within 7 days. If payment isn't received within 7 days, the auction will be revoked and a Non-Paying Bidder alert will be filed. Shipping: Packages are usually shipped within 48 hours of payment receipt (excluding Saturday/Sunday) International buyers, whatever the custom duty or charges if any will be borne by the buyer. As different countries charge Different Custom Duty. Buyer is responsible for Paying The charges. Combined shipping is done at the sellers discretion. If you purchase more than one item from us, they may arrive in separate packages. Returns: All items are sold as-is. We accept returns only if the item was not as described in the auction. Buyer must return the item exactly as received within 7 days and will be responsible for all additional shipping charges. We do our best to present accurate, detailed information about every item we sell. If you have any questions, please contact us before placing your bid or Buying.

“NEW PIECE IN BOX OPEN CONDITION.BOX WAS OPEN FOR PHOTOGRAPHY PURPOSE.”

Brand	pantech solutions
Model	PS 8086
