Pts 040 Frequency Synthesizer 0.1-40mhz.: 0.1hz. Resolution

US $1,000.00

Linlithgow, United Kingdom
Jan 29th

Open on mobile:
QR code

PTS 040 FREQUENCY SYNTHESIZER For sale is one PTS 040 frequency synthesizer covering the frquency range 0.1 MHz. to 40MHz.with a resolution of 0.1Hz. This is an ex. R.A.F. instrument and has been rack mounted. The instrument is fully funtional and in very good condition I am able to check the resolution to 1 Hz. but not to the full accuracy of 0.1Hz. The instrument shown has been sold the one offered is the same model, in the same condition The instrument may be returned within 7 days of receipt for a refund of the bid price .Buyer pays all shipping costs.Do not bid if you are not prepared to accept these conditions. NOTE :The output is via a BNC connector on the rear panel, this may be altered to the BNC. connector on the front panel Details:- 0.1 MHz to 40 MHz +3 to +13 dBm output Very low phase noise Fast switching, 5-20 µs Fully programmable, BCD or GPIB Low power consumption, high reliability 7 decades of DDS resolution available (with phase-continuous switching) SPECIFICATION:- Frequency Range: 0.100 000 0 MHz to 39.999 999 9 MHz Resolution: 0.1 Hz Accuracy: same as frequency standard Control: manual by 10-position dial; remote by TTL-level parallel entry BCD or GPIB (optional) Switching Time (to within 0.1 radian at new frequency) 10 MHz digit: 20 µseconds 1 MHz - 0.1 Hz digit: 5 µseconds Output Level: +3 to +13 dBm (1V max, 50 ? ), metered in dBm and volts(rms) Flatness: +0.4 dB Impedance: 50 ? Control: manual by front panel control; remote by analog voltage Spurious (at full power output, +13 dBm) Outputs Discrete: -75 dBc Harmonics: -35 dBc at full output (-40 dBc at lower level) Phase Noise: -75 dBc (0.5 Hz to 15 KHz) including effects of internal standard (1Hz): 100 Hz/ -125 dBc, 1 KHz/ -135 dBc, 10 KHz/-135 dBc, 100 KHz/ -137 dBc Noise Floor: -138 dBc/Hz Frequency Internal: OCXO or TCXO Standard 3x10-9/day 1x10-8/day ± 1x10-8/0-50° C ± 1x10-6/0-50° C 1x10-6/year 2x10-6/year External Drive: 10 MHz, 0.4 Vrms into 300 ? ; 5 MHz, 0.5 Vrms into 300 ? Aux. Output: 10.000 MHz, 0.4 Vrms into 50 ? (Note: internal or external standard required for operation) General:- Operating Ambient: 0 - 55° C, 95% R.H. Power: 105 - 125V, 50 - 400 Hz, 40W (100, 220, 240V optional) Dimensions: 19 x 5.25 x 18 inches (relay rack or bench cabinet) Weight: 35 lbs. ITEM LOCATION U.K., SHIPMENT TO MAINLAND U.S.A. FREE For more electronic instruments visit my E-bay shop . If paid by Paypal purchases will be shipped by a "SIGNED FOR" courier only. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
