Pwm Pulse Frequency Duty Cycle Adjustable Square Wave Signal Generator Module

US $12.99

Shenzhen, China
Jul 31st

Open on mobile:
QR code

Store category Sign Up Now ! You may also like PWM Pulse Frequency Duty Cycle Adjustable Square Wave Signal Generator Module Product Description 1.Description: XY-KPWM signal generator is a device that provides electrical signals at a variety of frequencies, square wave, and output levels.It is used as a signal source or excitation source for testing.Widely used in production practice and technology. 2.Features: 1>.With outer casing 2>.LCD high definition display 3>.Support UART 4>.Support frequency adjustment 5>.Support duty cycle adjustment 6>.High precision detection 7>.Support power-down memory function 8>.1-Channel PWM output 9>.Dual Work Mode 10>.Knob supports lock function to avoid misoperation 11>.Support enable output 3.Parameters: 1>.Product name: XY-KPWM PWM Signal Generator; 2>.Model: XY-KPWM; 3>.Work Voltage:DC 3.3V-30V; 4>.Frequency range(Normal mode):1Hz~150KHz; 5>.Frequency range(Precise mode):1Hz~15KHz; 6>.Frequency accuracy:2%; 7>.Duty cycle accuracy:1% at Normal mode; 8>.Duty cycle accuracy:0.1% at Precise mode; 9>.Duty cycle range:0.00%-100%; 10>.Output Current:About 5-30mA; 11>.Output amplitude:Same to input voltage; 12>.Work Temperature:-40~85; 13>.Work Humidity:0%~95%RH; 14>.Size:79*43*37mm; 4.Frequency set range: There is two work mode so it have two frequency range. Normal mode:Frequency range 1Hz~150KHz.Duty cycle range 000%-100%.Duty cycle accuracy 1%. Precise mode:Frequency range 1Hz~15KHz.Duty cycle range 0.00%-100%.Duty cycle accuracy 0.1%. Enter the settings interface when short press rotary switch in the normal running status to select frequency range.Rotary potentiometer to set frequency value. Keep press rotary switch for 10second to switch Normal mode and Precise mode. Keep press for 5second to locking parameters to protect the parameters from being modified. Pay attention to the position where the decimal point moves when rotary potentiometer.. Display ‘XXX’.No decimal point,The minimum frequency is 1Hz.The frequency range is 1Hz ~ 999Hz. Display ‘X.XX’.The decimal point is the penultimate, The minimum frequency is 0.01KHz.The frequency range is 1.00KHz ~ 9.99KHz. Display ‘XX.X’.The decimal point is the third last,The minimum frequency is 0.1KHz.The frequency range is 10.0KHz ~ 99.9KHz. Display ‘X.X.X’.The decimal point is fully lit,The minimum frequency is 1KHz.The frequency range is 1KHz ~ 150KHz. For example: Display ‘100’ means PWM output frequency is 100Hz; Display ‘1.91’ means PWM output frequency is 1.91KHz; Display ‘52.1’ means PWM output frequency is 52.1KHz; Display ‘1.3.4’ means PWM output frequency is 134KHz; 5.Duty cycle set range: Short press potentiometer to select set duty cycle and rotary potentiometer to set duty cycle value. 6.Use steps: 1>.Connect to power supply; 2>.Press rotary switch for 10second to switch Normal mode and Precise mode; 3>.Short press rotary switch to set frequency and change value by rotating switch; 4>.Press rotary switch for 2second to set duty cycle; 5>.Keep press for 5second to lock set parameters; 6>.Test; 7>.Press button ‘ON/OFF’ to turn on or off PWM output; 8>.Remove power and connect load to use module. 7.Application: 1>.Square wave signal generator, generating square wave signal for experimental development; 2>.Used to generate a square wave signal that controls the motor driver; 3>.Generate adjustable pulses for use by the MCU; 4>.Dimmer; 5>.Speed governor; 8.Note: 1>.It’s 1-channel PWM output signals. 9.Package: 1>.1pcs XY-KPWM PWM Signal Generator; Payment Shipping Policy Return Policy About us Contact us Payment 1.All payments must be prepaid. Shipping Policy 1. We are not responsible for undeliverable address, we reserve the right to charge the shipping fee again for returned items due to wrong address. 2. We will ship out your package by China post as soon as possible, it usually takes around 7-14 business days (USA, CA, AU, UK), others country takes around 10-20 business days (Brzil, India, RU), exact delivery time depends on postal process. 3. If you do not receive your item by 30 business days, Please feel free to contact us via ebay mail system, we will try our best to resolve any problems with you. 4. the import tax/duty is the buyer's responsibility, not included in the price and the shipping fee. It is charged by the custom of your country. (Pls note, business days means Sat. & Sun. excluded) Return Policy 1. We offer 30 days money back guarantee return policy . 2. Our warranty does not extended to any products that are physically damaged or that are not under normal operating conditions as a result of misuse or improper installation on the buyer/user's part. 3. For all returned products, buyers MUST contact us for the returning address. 4. In all cases, buyers pay shipping fees at their own cost to return products for exchange or refund. We will be responsible for the postage of replacements. Refund will be made upon receipt of the returned item. About us We have office and warehouse in Australia, UK and US to ensure fast shipment and after-sale service. We have more than 50 employees devoting to customer satisfaction. And more brands will be show in our store in near future. Contact us Our customer-oriented service strives for positive feedbacks with all 5 star selling ratings. Please feel free to contact us via eBay message once you have any question before you giving us negative feedback or open case. We will reply in 24 business hours. Business time: GMT8 (9:00-18:00) from Monday to Friday Feedback

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Frequency range(Precise mode)	1Hz~15KHz
Brand	Unbrand
Frequency accuracy	2%
Country/Region of Manufacture	China
Duty cycle accuracy	1% at Normal mode
Work Voltage	DC 3.3V-30V
Duty cycle range	0.00%-100%
Model	XY-KPWM
Output Current	About 5-30mA
Frequency range(Normal mode)	1Hz~150KHz
UPC	Does not apply
