Rohde & Schwarz Upl16 Gsm Audio Analyzer W/ Options B4, B6, B8, B9, B10 & U81

US $3,950.00

Laguna Hills, California, United States
Feb 12th

Open on mobile:
QR code

Rohde & Schwarz UPL16 GSM Audio Analyzer w/ Options B4, B6, B8, B9, B10 & U81 Audio Analyzer R&S UPL16 provides all the necessary audio signals and performs acoustical measurements. Digital Radiocommunication Tester R&S CMD or R&S CMU is used to establish the call. For some test cases the speech codec is also used. Audio Analyzer R&S UPL16 has the same superior analysis concept as all members of the R&S UPL family. The instrument is able to handle both analog and digital processing. It carries out practically all types of measurement in the audio range from frequency response measurements to distortion measurements, FFT analysis, etc. All the details about test functions and concept of operation can be found in the data sheet of the Audio Analyzer R&S UPL. The R&S UPL16 is especially designed for acoustical tests on GSM mobiles. It is equipped with the digital audio interface (DAI) as defined in GSM phase 2 recommendation 11.10, section 36.4. Thanks to this interface the R&S UPL16 can act as a system simulator or simulate a mobile. To drive an artificial head directly without additional amplifiers, the generator output of the R&S UPL16 is matched to the impedance of the artificial mouth by a built-in transformer on the rear panel of the R&S UPL16. GSM 11.10, section 30 defines 15 speech teleservices tests for GSM mobiles, generally referred to in this document as acoustical test cases. All these measurements are supported by the software package delivered with the instrument. · Built-in digital audio interface (DAI) · Test cases according to GSM 11.10 phase 2 · All kinds of analog and digital test signals including artificial voice · Analog and digital measurements · A-Law codec Options: B10 - UNIVERSAL SEQUENCE CONTROLLER, B4 - REMOTE CONTROL, B6 - EXTENDED ANALYSIS FUNCTIONS, B8 - MOBILE PHONE TEST SET, B9 - VALIDATED MOBILE PHONE TESTS UPL- FOR AIR INTERFACE TESTS ACCORDING TO 3GPP TS 26.132, U81 - ACOUSTIC TESTCASES WITH CMU Tested. Guaranteed to work. No manual or other accessories other provided. CA residents add 8% CA State Sales Tax. Please contact sales@gstestequipment.com or call (949) 679-5561

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Rohde Schwarz
Model	UPL16
