Rotary Switch 16 Position 7 Pole New Us.military Grade 16x7 Contact 125 Ac-5 Amp

US $475.00

San Jose, California, United States
Jan 29th

Open on mobile:
QR code

NEW Rotary Switch 16 Position 7 pole US.Military Grade 16x7 contact 125 AC -5 Amp Part #: 29207A US Military part # NSN 5930-01-095-7701 Spec: Contact :16 Selector A-P Pole : 7 stages ,each stage has 16 contact Total Contact :102 Height : 6 " Diameter : 3 Mounting bracket : 3" x 3" self-threaded ,takes 4 bolts NSN FSC NIIN Shelf Hazmat DEMIL 5930-01-095-7701 Item Description: SWITCH, ROTARY 5930 01-095-7701 0 P A CIIC HCC ESD PMIC Critical U S Y Technical Data Part Images (0) Demand History (0) Restrictions/Controls 5930-01-095-7701 ( L02890, 29207A, 01-095-7701 ) Master Cross Reference Data Mfg. Part Number ISC RNVC RNCC HCC MSDS SADC DAC 29207A 5 1 3 L02890 2 3 5930-01-095-7701 ( L02890, 29207A, 01-095-7701 ) Characteristics Data MRC Criteria Characteristic STYL STYLE DESIGNATOR 1 TAP, CIRCUIT SELECTOR ABHP OVERALL LENGTH 5.813 INCHES NOMINAL ABKW OVERALL HEIGHT 2.812 INCHES NOMINAL ABMK OVERALL WIDTH 2.812 INCHES NOMINAL AFBH INDIVIDUAL SECTION QUANTITY 7 AJZE SWITCH CONTACT BASIC DESIGN NONPILE-UP SYMMETRICAL AKPX POLE QUANTITY 2 EACH SECTION REAR AKPY THROW QUANTITY 6 EACH SECTION REAR CSHW CONTACT SWITCHING ACTION BREAKS BEFORE MAKES EACH SECTION REAR CQMK CONTACT VOLTAGE RATING IN VOLTS 125.0 AC AT SEA LEVEL 30.0 DC AT SEA LEVEL CTHF CONTACT LOAD CURRENT RATING 5.0 AMPERES RESISTIVE LOAD AC AT SEA LEVEL 5.0 AMPERES RESISTIVE LOAD DC AT SEA LEVEL CRJH SWITCH ACTUATOR INDEXING POSITION QUANTITY 6 SINGLE ACTUATOR CSLC SWITCH ACTUATOR POSITIONING INCREMENT 22.5 DEGREES SINGLE ACTUATOR CTDN SWITCH ACTUATOR STOP DEVICE TYPE ADJUSTABLE STOP SINGLE ACTUATOR CRSJ SHAFT TYPE RECTANGULAR/SQUARE, THREADED HOLE SINGLE ACTUATOR ABXF SHAFT LENGTH 1.219 INCHES NOMINAL SINGLE ACTUATOR CRTY SQUARE SHAFT SIZE 0.250 INCHES NOMINAL SINGLE ACTUATOR CSCF TERMINAL TYPE TAB W/SCREW AXGY MOUNTING METHOD BASE AND THREADED HOLE SINGLE MOUNTING FACILITY THSD THREAD SERIES DESIGNATOR UNC SINGLE MOUNTING FACILITY CQJX NOMINAL THREAD SIZE 0.190 INCHES SINGLE MOUNTING FACILITY AAJD THREAD CLASS 2B SINGLE MOUNTING FACILITY CMLP THREAD QUANTITY PER INCH 24 SINGLE MOUNTING FACILITY CQYJ MOUNTING FACILITY PATTERN FOUR POSITION RECTANGULAR SINGLE MOUNTING FACILITY AFDS LONGEST HORIZONTAL DISTANCE BETWEEN MOUNTING CENTERS 2.297 INCHES NOMINAL SINGLE MOUNTING FACILITY AFDV LONGEST VERTICAL DISTANCE BETWEEN MOUNTING CENTERS 2.297 INCHES NOMINAL SINGLE MOUNTING FACILITY CBBL FEATURES PROVIDED ACTUATOR KNOB FEAT SPECIAL FEATURES ITEM MUST COMPLY WITH REQUIREMENTS OF DESC PRODUCTION STANDARD NO. L02890; FOR NAVY NUCLEAR PROPULSION PLANT PRODUCTS ONLY CRTL CRITICALITY CODE JUSTIFICATION FEAT ABFE III HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION DUSTPROOF AFCQ III KNOB MANUFACTURER CODE 82121 AFCY III KNOB MANUFACTURER PART NUMBER A PRMT III PRECIOUS MATERIAL SILVER PMLC III PRECIOUS MATERIAL AND LOCATION CONTACT SURFACES SILVER
