Rotary Table 3" / 75mm With 65mm Lathe Chuck For Milling & Drill Machine

US $5100

DELHI, DELHI, India
Oct 29th

Open on mobile:
QR code

ROTARY TABLE TILTING FOR MILLING AND DRILL MACHINES 3"- 75 MM with 65 mm SELF CENTRING CHUCK HIGH QUALITY ITEM Precision 3" Tilting Rotary Table supplied with Mounting Back Plate and 65 mm 3 Jaw Self centring Lathe chuck. The Rotary Table can be tilting up to 90 degrees. Precision Mini Rotary Table 3" 75 mm is manufactured from Seasoned casting. Precisely maintained Chuck Run Out and Bottom Surface for accurate work. Table graduated 0-360 degrees in 5 degree divisions Winding handle is graduated 0-10 degrees in 5 minute divisions Application: Horizontal/Vertical Rotary Tables are extremely useful accessories for a milling machine. Simple to operate, they allow easy work handling and have many varied applications including: Machining - Milling curved profiles and angled faces relative to a center line. Drilling or milling to polar co-ordinates and, when mounted vertically with a tail stock they can be used to machine shafts or spindles. The versatile units can also be used on drilling, boring or slotting machines permitting an even greater range of operations. Machining - To establish the initial work piece position simply loosen the zero Collar locking handle and rotate the zero collar anti-clockwise for about half A turn. The worm is now disconnected from the worm wheel drive, the table is Free to turn independently to the crank handle and the work piece may now be Accurately aligned. To re-engage simply turn the zero collar in the clockwise Direction and re-tighten the locking handle. A rotary table can be used: To machine spanner flats on a bolt To drill equidistant holes on a circular flange To cut a round piece with a protruding tang To create large-diameter holes, via milling in a circular tool path, on small milling machines that don't have the power to drive large twist drills (>0.500"/>13 mm) To mill helix To cut complex curves (with proper setup) To cut straight lines at any angle EMAIL US FOR ANY QUESTION ? TERMS & CONDITIONS:- Paying with us is very easy thru PayPal.All our items are delivered to your doorstep. We cannot take any responsibility for the delivery of orders due to local import regulations in your respective countries. Your order may be subject to import duties and taxes, which are charged once your package reaches your country. We send all your shipments through registered mail and courier. All items will reach you within 8 to 12 days, in most cases we have seen our customers receiving them within a week. We will be shipping your items within 48 hours of your cleared payments. purchases .We will try our level best to serve you excellent.In case we are wrong on description, we will give you full refund or replacement. Please don't be harsh with your feedback, before leaving a negative feedback please do contact us to solve the issue. We are a upcoming online retailer for Engineering Tools, Machine Tools Accessories, Cutting Tools, Measuring Instruments, Diamond Tools, etc. We have wide range of Engineering Supplies and We also make Tools as per specifications.We are here to serve you 24 x 7. The Items we supply are Quality and at low rates as we are manufacturing most of the items. For Bulk Purchase do email us at " Ask the Seller question"
