Rotary Table 3" (80mm) Horizontal & Vertical + 50mm Lathe Chuck + Backplate

US $94.99

DELHI, DELHI, India
Aug 31st

Open on mobile:
QR code

Supplied complete with a key as well as set of tee nuts and studs to secure it into place. ROTARY TABLE -Table: 3" Diameter -Table Height: 1 5/8" -Base Dimensions: 4. 1/8" x 3. 1/4" -Center Height in Vertical Position: 1. 11/16" -T-Slots: 5/16" -Operates in the Horizontal or Vertical position -Hand Wheel calibrated to 10 degrees per revolution with 1/4 degree increment graduations. -Table scale graduated in 5 degree increments. -Quality 3 jaw self centering chuck 50mm Diameter -Contra rotating rapid jaw adjustment mechanism. -Backplate is drilled and counterbored to fit a range of 3” and 4” rotary tables with 4 Slots Application: Horizontal/Vertical Rotary Tables are extremely useful accessories for a milling machine. Simple to operate, they allow easy work handling and have many varied applications including: -Milling :Milling curved profiles and angled faces relative to a centre line. Drilling or milling to polar co-ordinates and, when mounted vertically with a tailstock they can be used to machine shafts or spindles. The versatile units can also be used on drilling, boring or slotting machines permitting an even greater range of operations. -Machining - To establish the initial work piece position simply loosen the zero Collar locking handle and rotate the zero collar anti-clockwise for about half A turn. The worm is now disconnected from the worm wheel drive, the table is Free to turn independently to the crank handle and the work piece may now be Accurately aligned. To re-engage simply turn the zero collar in the clockwise Direction and re-tighten the locking handle. Rotary table can be used for : To machine spanner flats on a bolt To drill equidistant holes on a circular flange. To cut a round piece with a protruding tang To create large-diameter holes, via milling in a circular tool path, on small milling machines that don't have the power to drive large twist drills (>0.500"/>13 mm) To mill helixes To cut complex curves (with proper setup) To cut straight lines at any angle

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	RT3
MPN	RT3
Country/Region of Manufacture	India
Brand	OMEX
UPC	Does not apply
