Rotary Table 4" Inch/100 Mm Horizontal - Vertical Engineering Tool

US $98.00

DELHI, DELHI, India
Aug 29th

Open on mobile:
QR code

Rotary Table 4" 100mm Horizontal Vertical Model Milling Machine 4 Slots Product details : The Metal : High quality 18 Gauge Mild Iron steel with Brass Accents. THIS NEAT LITTLE ROTARY TABLE, WITH A DIAMETER OF 100MM, CAN BE USED FOR A VARIETY OF MILLING, DRILLING AND MARKING OUT OPERATIONS IN THE HOME ENGINEER'S WORKSHOP. THERE ARE FOUR TEE SLOTS FOR SECURING THE WORK, FACES MACHINED AT RIGHT ANGLES FOR HORIZONTAL AND VERTICAL MOUNTING AND 7MM SLOTS FOR SECURING TO THE MACHINE TABLE. THE INDEXING HANDLE, WHICH ROTATES ONCE FOR EVERY TEN DEGREES OF TABLE ROTATION, IS SUBDIVIDED IN DEGREES AND QUARTER DEGREES. THE CENTRE HEIGHT WHEN MOUNTED VERTICALLY IS 40MM. SUPPLIED WITH WORK CLAMPING KIT. VERTICAL AND HORIZONTAL MOUNTING TEE SLOTS FOR SECURING WORK WHEEL MARKED IN DEGREES AND QUARTER DEGREES Description: A Precision work positioning device used in metalworking, enabling the operator to drill or cut work at exact intervals around a fixed axis. Rotary tables are most commonly mounted "flat", with the table rotating around a vertical axis, in the same plane as the cutter of a vertical milling machine. An alternate setup is to mount the rotary table on its end (or mount it "flat" on a 90° angle plate), so that it rotates about a horizontal axis. In this configuration a tailstock can also be used, thus holding the work piece "between centers." Application: Horizontal/Vertical Rotary Tables are extremely useful accessories for a milling machine. Simple to operate, they allow easy work handling and have many varied applications including: Milling : Milling curved profiles and angled faces relative to a centre line. Drilling or milling to polar co-ordinates and, when mounted vertically with a tailstock they can be used to machine shafts or spindles. The versatile units can also be used on drilling, boring or slotting machines permitting an even greater range of operations. -Machining - To establish the initial work piece position simply loosen the zero Collar locking handle and rotate the zero collar anti-clockwise for about half A turn. The worm is now disconnected from the worm wheel drive, the table is Free to turn independently to the crank handle and the work piece may now be Accurately aligned. To re-engage simply turn the zero collar in the clockwise Direction and re-tighten the locking handle. Rotary table uses: To machine spanner flats on a bolt To drill equidistant holes on a circular flange. To cut a round piece with a protruding tang To create large-diameter holes, via milling in a circular tool path, on small milling machines that don't have the power to drive large twist drills (>0.500"/>13 mm) To mill helices To cut complex curves (with proper setup) To cut straight lines at any angle SIZES & VARIATIONS: (A) 3" / 80mm Rotary Table Horizontal Vertical 4 Slots : -Table: 4" Diameter -Table Height: 1 5/8" -Base Dimensions: 4. 1/8" x 3. 1/4" -Center Height in Vertical Position: 1. 11/16" -T-Slots: 5/16" -Operates in the Horizontal or Vertical position -Hand Wheel calibrated to 10 degrees per revolution with 1/4 degree increment graduations. -Table scale graduated in 5 degree increments. Payment Policy Paying with us is very easy through PayPal.Your order may be subject to import duties and taxes, which are charged once your package reaches your country, We are not liable for the same. Shipping Policy Your product will be shipped within 1-3 Business days after receiving payments, Via Fedex/DHL/Aramex/My Pacco or India Post with Tracking facility. We ensure the product reaches you at the earliest. Please provide your Correct Address & telephone no, as the shipping company might need it at the time of delivery.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Setting Position	Horizontal/Vertical
MPN	Does Not Apply
Operation	Manual
Brand	Unbranded
UPC	Does not apply
