Sale!!! Sbm10-1 Tiny Geiger Counter Tube Nos For Radiometer Detector Lot Of 5

US $498

  • Troitsk, Moscow region, Russian Federation
  • Jun 4th
New SBM10-1 tiny Geiger tube for beta- and gamma-rays detection. The same as SBM10 but with long Cathode lead welded, rare! Laboratory checked. Lot of 5. Technical parameters: Gas filling Neon+Halogen Cathode material and density Stainless Steel 50 mg/cm2 Maximum length (inch/mm) 1.04/26 Effective length (inch/mm) 0.6/15 Maximum diameter (inch/mm) 0.24/6 Effective diameter (inch/mm) 0.22/5.55 Operating temperature range °C -50 to +60 ELECTRICAL SPECIFICATIONS Recommended anode resistor (meg ohm) 3-15 Maximum starting voltage volts 320 Recommended operating voltage volts 400 Operating voltage range volts 370 - 480 Maximum plateau slope (%/100 volts) 15 Dead time (microseconds) 64 Gamma sensitivity Co60 cps/mr/hr 3.3 Tube capacitance pf 2 Weight grams 0.8 Ideal for keychain personal radiation detectors. Please ask any questions by email im81.max@gmail.com. I have discount options up to 20% in some cases! Thank you for purchase!
