Scmi Si 400 Nova Slider Saw

US $1700

Nacogdoches, Texas, United States
May 25th

Open on mobile:
QR code

SCM SI400 Nova Slider SLIDING CARRIAGE: MAXIMUM CUT QUALITY GUARANTEED OVER TIME. The carriage will never require adjustment due to its structure with arch-ground steel slideways (Scm exclusive and patented solution) so it can carry loads four times higher than others. “ARC” PROFILE: FOR EXCELLENCE IN MACHINING. • no play and no need for adjustments over time • higher loading capacity • +/-0,05 mm tolerance on the entire carriage length for straight and high quality cutting. The horizontal positioning of the guides ensures protection from dust therefore improving the sliding of the carriage. SLIDING CARRIAGE: SMOOTH SLIDING AND A SOLID WORK SURFACE. The wide section of the carriage, with closed reticular geometry, provides extreme rigidity and minimum deflection. A smooth operating motion is guaranteed over time by the system of sliding bearings running on hardened steel guides using an exclusive method of mechanical fixing. nova SAW UNIT: A PERFECT CUT. Maximum torsional rigidity and the total absence of vibration through the closed loop structure of the saw unit which ensures perfect alignment of the blades during tilted and difficult cuts. MANUAL MOVEMENTS: ALWAYS USER FRIENDLY AND PRECISE. Ease of use in every day operation due to the dedicated gear box, fully protected from dust (Scm patented solution), that provides a smooth and direct transmission. Every minimum hand wheel movement corresponds to a precise blade adjustment. MANUAL ADJUSTMENT OF THE SCORING UNIT: SIMPLE AND EFFECTIVE. Vertical and horizontal adjustments are carried out by user-friendly mechanical levers that operate directly making precise and smooth movements. The useful mechanical stops allows immediately finding of the set position. The positioning of the controls allows their use without moving from the front of the machine. SLIDING SWINGING ARM SUPPORT by means of the exclusive aluminium extrusion for the very best smooth and precise operation. The adjusting dust scrapers ensure high efficiency over time. L’invincibile, class PARALLELOGRAM FRAME: THE IMMEDIATE CUT. The micrometric adjustment with LCD display allows rapid setting up to carry out very precise angular cuts. Specifications: Squaring Capacity - 3200 x 3200 mm Cutting Width one Rip Fence - 1270 mm Max Main Blade Diameter - 400 mm Max Xcoring Blade Diameter - 120 mm Cutting Height @ 90/45 Degrees - 140/97 mm Main Blade Motor Power - 7 Kw Scoring Blade Motor Power - 0.9 Kw Main Blade Speed - 3000-4000-5000 rpm Scoring Blade Speed - 8500 rpm Exhaust Outlet Diameter at the Base - 120 mm Exhaust Outlet Diameter on Overhead Protection - 100 mm Exhaust Outlet Diameter Riving Knife - 60 mm Extraction Air Flow rate ot 20m/sec Net Weight Basic Machine - 1070 Kg Electrical: 230v/3 ph Year: 2015
