Sdm120ct-modbus Multifunction 1p Single Phase Din Rail Energy Meter With Rs485

US $89

Shenzhen, China
May 24th

Open on mobile:
QR code

SDM120CT-Modbus 230V 2 Wire Single Phase DIN Rail Energy Meter RS485 kwh kvarh U I P Q PF Hz + Free Shipping with Track Number Product Description The device can be used together with current transformer, if you want, pls contact us! Thx! Features: Measures kWh, Kvarh, KW, Kvar, KVA, PF, Hz, dmd, V, A, etc. Bi-directional measurement IMP & EXP Two pulse outputs RS485 Modbus Din rail mounting 17.5mm 0.1VAC direct connection Better than Class 1 accuracy Application: The energy-meter"with a blur back-lighted LCD screen for perfect reading" are used to measure single-phase like residential, utility and industrial application. The unit measures and displays various important electrical parameters, and provide a RS485 communication port for remote reading and monitoring. Bi-directional energy measurement makes the unit a good choice for solar PV energy metering. The compact design and din rail installation provides a easy and economical solution for your metering demand. General Specification: Voltage AC (Un): 230V Voltage Range: 176~276V AC Base Current (Ib): 0.1VAC Power Consumption: <2W/10VA Frequency: 50/ 60Hz(±10%) AC voltage withstand 4KV for 1 minute Impulse voltage withstand 6KV-1.2uS wavform Overcurrent withstand 30Imax for 0.01s Pulse Output Rate:1000imp/kWh (default) 100/10/1 imp/kWh/kVarh (configurable) Display: LCD with blue backlit Max. Reading: 99999.9kWh Accuracy: Voltage: 0.5% of range maximum Current: 0.5% of nominal Frequency: 0.2% of mid-frequency Power Factor: 1% of Unity Active Power: 1% of range maximum Reactive Power: 1% of range maximum Apparent Power: 1% of range maximum Active Energy: Class 1 IEC62053-21 Class B EN50470-3 Reactive Energy: 1% of range maximum Environment: Operating Temperature: -25℃ to +55℃ Storage & Transportation Temperature: -40℃ to +70℃ Reference Temperature: 23℃±2℃ Relative Humidity: 0 to 95%, non-condensing Altitude: up to 2500m Warm up time: 10s Installation category CAT II Mechanical Environment M1 Electromagnetic environment E2 Degree of pollution 2 Output: Pulse Output The meter provides two pulse outputs. Both pulse outputs are passive type. Pulse output 1 is configurable. The pulse output can be set to generate pulses to represent total / import/export kWh or kVarh. The pulse constant can be set to generate 1 pulse per: 0.001(default) /0.01/0.1/1kWh/kVarh. Pulse width: 200/100/60ms Pulse output 2 is non-configurable. It is fixed up with total kWh. The constant is 1000imp/kWh. RS485 output for Modbus RTU The meter provides a RS485 port for remote communication. Modbus RTU is the protocol applied. For Modbus RTU, the following RS485 communication parameters can be configured from the Set-up menu. Baud rate: 1200, 2400, 4800, 9600 Parity: NONE/EVEN/ODD Stop bits:1 or 2 Modbus Address: 1 to 247 Mechanics: Din rail dimensions: 17.5x119x62 (WxHxD) DIN 43880 Mounting: DIN rail 35mm Sealing: IP51 (indoor) Material: self-extinguishing UL94V-0 Package List: 1 x SDM120CT-Modbus DIN Rail Energy Meter Payment Method We accept only Paypal for both domestic and international. We will ship to the shown address on you PAYPAL Payment notice,Please confirm your shipping address in the PayPal Account. If buyer want to delay the payment because of financial problem, please contact me by the ebay message within 3 days. Shipping Detail Ship by Post Air-mail within 1-2 working days after full payment is received. The shipment usually takes 15-45 business days to Worldwide. We also provide international Expressed delivery such as EMS, DHL and UPS,extra shipping fees is needed. The shipping time may vary, depends on receiver's location. Feedback Policy We will leave positive feedback to buyer as soon as buyer pays for the item. Leaving Negative feedback or Netural Feedback is never a good way to resolve problem .We hightly appreciate that you can contact with us before you leaving Negative feedback or Neutral feedback .We will offer help to resolve your problems as fast as possible. Customer Service Work Time If you have any questions,Please contact with us via eBay message or our customer service e-mail . please be advised that e-mails will be replied by our customer services officers Mon. - Fri. 09:00 - 20:00 and Saturdays 09:00 – 18:00(Excluding Weekends and Public Holidays) You may expect to receive a response to your inquiry within 24 hours. (Excluding Weekends and Public Holidays) On May-24-16 at 03:13:06 PDT, seller added the following information:On May-24-16 at 09:10:59 PDT, seller added the following information:
