Servo Type 140 Y Axis Power Feed For Bridgeport Style Milling Machine

US $7460

  • Shelton, Connecticut, United States
  • Jun 5th
Open on mobile:
QR code
Servo Type 140 Y-Axis Power Feed This Power Feed is used, in working condition. It came off a Bridgeport Mill and can fit on any similar styled milling machine. It comes without mounting brackets and does not have stops or a stop rod. The following are the specifications as listed on Servo's website: Semi-automated machining on Class 1 mills to 3 hp. Peak Torque (half-wave series motor): to 140 in.- lb. / 15.8 NM torque Intermittent Torque: 105 in.- lb. / 11.9 NM Continuous Torque: 90 in.- lb. / 10.2 NM Variable Feed Rate:  .75-25 IPM / 19-635 mm/min (table & cross)  .5-12 IPM / 13-305 mm/min (knee) Rapid Traverse:  35 IPM / 889 mm/min (table & cross) 12 IPM / 305 mm/min (knee) Gear Reduction Ratio (motor to screw shaft): 72:1. Helical gearing and torque limiting friction safety clutch with new and improved gear. Electrical: 110V, 50/60 Hz, 2.5A. Approx. weight: 15 lb. / 6.8 kg. The serial number is: 140-468638
