Sharp Universal Milling Machine - Model VH-3 - Table 12 x 51 approx - Vert/Horiz, US $2600 – Picture 0
Sharp Universal Milling Machine - Model VH-3 - Table 12 x 51 approx - Vert/Horiz, US $2600 – Picture 0

Sharp Universal Milling Machine - Model Vh-3 - Table 12 X 51 Approx - Vert/horiz

US $2600

  • Gardnerville, Nevada, United States
  • Jun 9th
Open on mobile:
QR code
We are offering a Nice Used Sharp Vertical Mill, with independent Horizontal and Vertical Spindles, Approx 12" x 51" Table size, 3 way power feeds, plus quill power feed, DRO, Large Kurt Vise. New Replacement cost around $45,000.00. Reasonable shipping may be available into parts of Nevada and California. Email any questions Thanks for Looking!!! Catalog Specifications: TABLE Working surface: 12" x 51" T-slot number, size: 3, 5/8" CAPACITY Table travel: x-axis 38" Saddle travel: y-axis 15" Ram travel: 20-1/16" Quill travel: z-axis 5-1/8" Knee travel: 18.5" Throat distance (min-max): 12.8"-30.7" VERTICAL SPINDLE Motor:  5 HP Wiring voltage: 220V or 440V, 3 Ph, 60 Hz Taper: #40 NST Speed (vari speed): 120-3,600 RPM Quill feeds (IPR): 0.0019, 0.0038, 0.0076 Head tilt - right to left (each way): 90? Head tilt - front-to-back (each way): 45? HORIZONTAL SPINDLE Motor:  7.5 HP Wiring voltage: 220V or 440V, 3 Ph, 60 Hz Taper: #50 NST Speeds (12): 35 - 1,382 RPM Spindle Center Line to Table (min-max):  7/8 - 19-3/8" DIMENSIONS AND WEIGHT Floor area (w x d): 107" x 90"' Height: 95-1/4" Net weight (lbs; approximately): 5,830 STANDARD EQUIPMENT: 3 HP Table Feed & Rapid Traverse Motor (for all 3 Axes) X & Y Table Feeds (1/2 - 24-7/8 IPM) w/ Rapid Traverse (116.5 IPM) Vertical Feed to Knee (1/4 - 12-7/16 IPM) w/Rapid Traverse (60 IPM)

Directions
