SHARS 3" 45° INDEXABLE FACE MILL SEHT INSERTS W/ CAT 40 ARBOR NEW Quality 100% Guaranteed! Using as coolant shell mill holder with face mill coolant style arbor screw 202-6295 Competitors' Regular Price: $319.00 Wholesale Price: $147.90 you save $171.10 53.64% off Our indexable face mill and inserts are manufactured by an ISO 9001 certified manufacturer with 60 plus years of hands-on experience in the CNC machining industry and which is also as OEM that produces highest quality European brands. Product Code 404-2247+202-5372 Product description 3" 45° Indexable Face Milling Cutter Feature: Cutting Diameter D: 3" Arbor Hole: 1" Height H: 1.970" Width A: 3.650" Depth of Cut ap: 0.236" No of Flute: 6 (Inserts no included, sold separately!) Insert Size: SEHT 43 (ISO1204) Product application Surface milling in difficult condition of steel, alloy steel, stainless steel, and heat resistant steel, cast iron and aluminum alloys. Product features Suitable for most face milling applications Reduces vibration on long overhang applications Chip thinning effect allows for increased table feeds High Positive cutting geometry Photo is only showing an example of face mill/end mill from this series. Benefit from the 45 degree lead angle allows an increase of feedrate by 50% over 90 degree face mill and also allows this face mill to used on smaller horse power mills. It uses industry standard SEHT / SEHW / SEHX 43 (ISO 1204) insert which has a positive 20 degree clearance angle. The insert pockets are designed to be 19 degree positive inclined to minimize vibration and each pocket has an chip escaping pathway to help preventing chip built-up on insert edge. Each insert pocket is designed to reduce run-out and extent insert life. Use SEKT / SEHT / SEHW 43 1204 insert (insert not included) Setting Angle: 45 degree Radial rake angle: -7 degree Axial rake angle: 19 degree CUTTING PARAMETER Product includes Insert NOT included Cat40 Shell Mill Holder Feature: Cat Taper: 40 Bore Dia. in Shell mill: 1" Gage Length: 1.97" Shell mill pilot T.I.R <0.0002" Product features H6 arbor tolerance to improve cutter chattering and overall cutting tool life T.I.R. 0.0002" measured from CAT40 taper to face and arbor Unique design feature in the flange to minimize the off-balance nature of CAT 40 taper specification. On the side of flange where a half spherical hole is located, a "wall" is built around this hole to compensate the weight of the metal chips lost from forming this spherical hole. This design allows the left side and right side of the holder to achieve 50-50 perfect weight distribution in its upright position, like the position inside a machine spindle. Symmetrical design in evenly weight distribution will minimize centrifugal force in high speed spinning and thus maximize the holder's ability to hold the cutting tool concentric to spindle rotation. Made from alloy steel harden to 54-60 HRc Taper ground to AT3 or better accuracy standard for maximum contact with spindle. All of SHARS CAT/BT/HSK tool holder use Stotz Air/Electronic Gaging for production and finish inspection. Stotz has been chosen by major aircraft companies as the best and most consistent gaging for tool holder shanks All critical surface are precision ground Each holder comes with a lab certificate on its taper accuracy and runout measurement Other import tool holder are ground before hardened which would lead to deformation and less accurate after the heat treat process; Shars tool holder is ground after heat treat would hold its accuracy over longer period of time Using as coolant shell mill holder with face mill coolant style arbor screw 202-6295 We have more REPLACEMENT ACCESSORIES available: Order# 424-1502 $8.00/pc Order# 404-1873 $3.00/pc Order# 404-4559 US $1.95 SEHT 1204 AFTN Insert Insert Screw M5X12 Key T20 Click the photo to the item page Order No. 404-1869 Order No. 404-2629 Order No. 404-2679 Order No. 404-2247 3" 90° Square Shoulder Indexable Face Mill 3" 45° Indexable Face Mill ONHU Inserts 3" 90° Square Shoulder Coolant Thru Indexable Face Mill 3" 45° Indexable Face Mill SEHW Inserts Order# 202-5162 Order# 202-5372 1" R8 Shell Mill Arbor CAT40 1'' Shell Mill Holder Order# 202-6295 $8.50/pc Order# 202-5313 $3.10/pc Coolant Style Arbor Screw Arbor Screw Arbor Dia.: 1''; Dia.: 0.75; Thread Size: 1/2''-20 Arbor Dia.: 1''; Dia.: 1.19; Thread Size: 1/2''-20 We also have different Face Mill and End Mill available, please visit my eBay store: All Available to Ship from Our eBay Store NOW! at Fixed Prices! If you need to speak to a sales person feel free to call. We are open Monday through friday 8:30 to 5:00 est. Phone:1-630-443-3244 Email: discountmachineshop@gmail.com click here to visit my Ebay store now SHIPPING: UPS Ground Buyer pays ACTUAL UPS shipping & insurance, and a $3.00 handling fee for this item to be shipped to all states within the continental United States. Hawaii, Alaska & and other United States Territories will ship via USPS. Canada will pay actual shipping costs plus duty fees via USPS. We can combine other auctions or store items to save on shipping. You may ask for freight cost before buying tools. Shipment will be made the same day as your payment is received and an UPS tracking number will be email to you. PAYMENT: We accept : VISA, MasterCard and E-Check on PayPal.com Illinois residents add 8% sales tax. RETURNS: If the item stated as brand new is found defective on arrival or incorrect item was shipped, buyer understands that the product will be repaired or replaced at seller's discretion, and be given a reasonable amount of time. Buyer is responsible for return shipping costs and insurance. Warranties are offered by the manufacturer and will be honored by the manufacturer. All shipping and handling fees will not be returned in any case. Any questions regarding our tools, feel free to email us at discountmachineshop@gmail.com Bonus: PayPal buyers get complimentary access to discount_machine's weekly newsletter.
