Sherline 4" Cnc Rotary Indexer

US $725.00

Vista, California, United States
Jan 30th

Open on mobile:
QR code

Compact American made computer controlled indexer About Sherline: Sherline tools have been manufactured in the United States for over 40 years and set the standard for small scale precision metalworking tasks as performed by model makers, mechanics, jewelers, prototypers, watch makers, clock makers, pen makers, engineers, inventors—anyone needing accurate small parts made from metal, wood or plastic. They are used in light industrial and second operation applications by many different industries as well as individual craftsmen in the home shop. The laser marking industry has also found much use for this compact table for marking round parts. A YouTube search for “Sherline Rotary Table” will also turn up some customer videos of the table in use. About the Sherline CNC Rotary Indexer: Clock makers or machinists with a need to cut gears, splines or drill radial hole patterns will find this accessory takes all the headaches out of repetitive indexing operations. Rotation increments can be entered on the controller keypad in either “Divisions” mode (0 to 999 divisions) or in “Degrees” mode (to 3 decimal places of a degree). Continuous rotation is also possible. Direction of rotation and speed are controllable. Once an amount is entered, you can index forward each time you hit the “Next” key or backward to previous settings using the “Previous” key. A “Jog” function allows non-programmed rotation in either direction in slow or fast speeds as long as the appropriate key is held down. Electronic backlash compensation is also available when changing directions, virtually eliminating backlash. Basic resolution is 28,800 steps per table revolution or ±0.006° per step. This allows for accurate machining of items like gears with odd numbers of teeth. Computations are made internally to many decimal places as on an electronic calculator to avoid cumulative errors. The rotary table package includes the 4? diameter table, stepper motor mount, stepper motor, connecting cables, power supply and programmable control box as well as a detailed set of instructions for its use. The unit is completely self-contained and requires no other electronics or drivers. Also included is a threaded adapter that can be used to attache any Sherline 3- or 4-jaw chuck to the surface of the table and a pair of hold-down clamps for mounting the rotary table to a Sherline mill. An optional #3701 90° fixture is available to mount the table vertically, and another fixture #3702 is an adjustable tailstock for supporting long stock on center with the table when it is mounted vertically. Operation of the indexer is fully explained in the included instruction manual as well as on Sherline’s highly informative web site. Also available is a complete line of benchtop, precision, manual, DRO and CNC lathes, mills and accessories. Key advantages of a Sherline rotary table include: · Designed and built in the USA by and for machinists · Immediate spare parts availability · Complete, illustrated instructions and technical support in proper English · Rigid design and high quality construction · Instrument quality finishes · One year warranty for home shop use Dimensions and travels: Rotation speed range: 1°/sec to 50°/sec (programmable) Resolution: 28,800 steps/rev (±0.006°/step) Backlash compensation: Programmable to zero Stepper Motor: 136 oz-in, 400 steps/rev Power supply input: 115 VAC, 50/60 Hz Power supply output stepper: 24VDC, 1 Watt The best source for more information about Sherline tools is the Sherline web site, which also includes a lot of related material of interest to machinists.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	Sherline
Model	8700
Country/Region of Manufacture	United States
MPN	8700
Brand	Sherline
