Smart Tweezer St1 Lcr Meter

US $125.00

Mesa, Arizona, United States
Jan 29th

Open on mobile:
QR code

SPECIFICATIONS Physical Specifications Operating Temperature: 0 °C to + 55 °C Storage Temperature: 40 °C to + 60 °C Relative Humidity: 0 % to 90 % (0 °C to 35 °C) 0 % to 70 % (35 °C to 55 °C) Altitude Operating: 0 – 2000 meters Storage: 10000 meters Battery Type: 1.5 V LR44 (357A) Alkaline or Air zinc Battery Life: 80 Hours typical with alkaline, 220 hours with air zinc battery Electromagnetic Susceptibility and Emission: Compatibility (EMC): FCC 15 part B Size: 14.0 x 2.5 x 3.0 cm (3.94 x 0.9 x 1.5 in) Weight: 53 grams (0.11 lb) Basic Specifications Measured Parameters: C, L, R, ESR, Rs, Rp Measuring Frequencies: 100 Hz, 1 kHz, 10 kHz Measurement rate: 1 time per second, default DC Voltage: 0 to 800 mV (Up to 8 V with optional slide switch manual setting) Resistance: 0.1 Ohm – 9 M Ohm 0.1 Ohm – 1 M Ohm Resolution: 0.01 Ohm Capacitance: 10 pF to 499 mF Inductance: 1 uH to 999 mH Battery life: minimum 120 hrs (Air-Zinc batteries) Detailed Accuracy Specifications Accuracy is specified at 18 °C to 28 °C (64 °F to 82 °F), with relative humidity to 90 %. Resistance Range: 0.1 Ohm – 5 MOhm Accuracy: 1 % in range 0.1 R – 1 M 2 % in range 1 M – 5 M Resolution: 0.01 R in range 0 – 10 R Test Frequency: 1 kHz Capacitance Range: 10 pF – 499 uF Accuracy: 5 % in range 20 pF – 499 uF Resolution: 0.5 pF in range 1 pF – 100 pF Test Frequency: 1 kHz C > 1000 pF 10 kHz C < 1000 pF 100 Hz C > 1 uF Inductance Range: 1 uH – 1 H Accuracy: 10 % in range 1 uH – 10 uH 5 % in range 10 uH – 100 uH 5 % in range 100 uH – 1 H Resolution: 0.5 uH in range 1 uH – 100 uH Test Frequency: 10 kHz L < 1 uH 1 k Hz L > 1 uH 100 Hz L > 1 mH Feature Summary Graphics Displays. Analog Bar Graph. Fully automatic measurement of Inductance, Capacitance and Resistance. Auto range: Meter automatically selects best range. Trace Graph: Oscilloscope like display for voltage measurement.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Slight signs of use. Unit still performs well, powers up and all functions work. Users manual included. unit is sold as-is.”
