Sonora Sdswma2-t Swm Only Amplifier,output 940 To 2150 Mhz,14 Db (sdswma2t)

US $35.06

United States
Mar 9th

Open on mobile:
QR code

Browse our Store | Ask a Question | Return Policy | Promotions | About Us Product DescriptionSpecificationPaymentShippingReturns Sonora SDSWMA2-T Swm Only Amplifier,output 940 To 2150 Mhz,14 Db Gain, 2 To 806 Mhz R [sd Swma2-t] Sonora SDSWMA2-T Swm Only Amplifier,output 940 To 2150 Mhz,14 Db Gain, 2 To 806 Mhz R [sd Swma2-t] International Customers: All electronic products are packaged for sale in the US with US voltage. Additional Information: Specifications Typical QC Limit Gain 2 to 806 MHz : -1 dB to-4 dB 940 to 1450 MHz: 12 dB to 11 dB 1450 to 2150 MHz :15 dB to 14 dB Maximum Output (32 equal transponders):.-1 dBm Maximum Output Power IM2 with 2 tones @ 0 dBm.-54 dBc -52 dBc min. IM3 with 2 Tones @ 0 dbm -56 dBc -54 dBc min. Pass band Flatness Any 24 MHz band 0.1 dB 0.2 dB Input Return Loss.12 dB 9 dB Output Return Loss .13 dB 10 dB Noise Figure 6 dB 7 dB Power Specifications Voltage 10 to 29 VDC Current 8 mA / channel Model SD SWMA2-T transformer 12 V 250 mA Country of Origin: China Product Description This item is brand-new, factory sealed. Indoor / Outdoor DBS line powered amplifier with 940 to 2150 MHz forward gain and passive 2 MHz to 806 MHz return. Specification Interfaces/Ports Ports 1 x Input 1 x Output General Information Product Type Signal Amplifier Product Name SD SWMA2 Line Amplifier Manufacturer Part Number SD SWMA2-T Manufacturer Sonora Design Associates Product Model SD SWMA2-T Marketing Information Indoor / Outdoor DBS line powered amplifier with 940 to 2150 MHz forward gain and passive 2 MHz to 806 MHz return. Brand Name Sonora Physical Characteristics Weight (Approximate) 6 oz Height 1.1" Width 2.8" Depth 1.4" Technical Information Input Voltage Range 10 V DC to 29 V DC Housing Die-cast Metal Gain 14 dB Frequency Range 940 MHz to 2150 MHz 2000 kHz to 806 MHz Title Product Title Sonora Sd Swma2 Line Amplifier - 2150 Mhz, 806 Mhz (SDSWMA2T) Payments We only accept Paypal. Shipping Most orders placed prior to 11AM PST ship same business day Some lightweight items ship Postal and can be shipped to a PO BOX. Most other orders will ship via UPS or FedEx. Please note we cannot ship UPS or FedEx to PO Box addresses. Expedited orders will ship 2nd Day Air Returns This item is eligible for return within 30 days of delivery. Returns of non-defective items will be charged a 15% restocking fee. Please visit our Returns Page for more information on Excluded Items, Damage Claims, and more details on requesting RA information. [ Read our full policy ] About Beach Audio Founded in August 2002, Beach Audio´s mission is to provide the best experience on the Internet for buying Consumer Electronics. We focus on making purchasing online a pleasant experience. We offer flat rate Ground shipping on all items less than 75 pounds that can be shipped via common carrier. Our sales office is located in beautiful town of Redondo Beach, California, just a few miles South of Los Angeles International Airport. We do not stock any inventory at our sales office. Instead, we ship from several warehouses located throughout the country. Our sophisticated fulfillment system will automatically ship from the warehouse location that is closest to your shipping address! Why are our prices so low? It´s simple. We have modeled our business much like a wholesaler. We sell in huge volume and have streamlined our operations to provide you with the best combination of price and service available anywhere. Hours of Operation 8AM - 5PM PST MON - THU, 8AM - NOON PST FRIDAY [ Read more ] Copyright© Beach Audio Inc, 2010

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Sonora
MPN	sdswma2-t
