THIS AUCTION IS FOR ONE (1) ABOVE SEEN - NEW / UNUSED SURPLUS STANCOR - HEAVY DUTY SUBMERSIBLE SUMP PUMP W/ OIL MINDER MODEL: SE-40 SERIAL NO. 57462 VOLTAGE: 115V / 60 Hz 1-PHASE 0.4 HP 5M CABLE DISCHARGE: 2-INCH NEW OLD STOCK SURPLUS, THIS BOX WAS PREVIOUSLY OPENED BEFORE WE RECEIVED IT, HOWEVER THE UNIT WAS NEVER USED. (SEE PHOTOS) THIS AUCTION IS FOR THE EXACT PUMP, AND ACCESSORIES SHOWN IN THESE PHOTOS, THERE ARE NO ADDITIONAL ACCESSORIES WITH THIS UNIT. ANY QUESTIONS FEEL FREE TO ASK ! Specifications.Input Voltage115/230, 1?Amps5/2.3 AHorsepower0.4Discharge (Optional)2"Maximum Head22 ftMax Rated Capacity64 GPMTDH 3000 GPH6 ftTDH 6000 GPHN/ATDH 9000 GPHN/ACable Length16 ftSpecial Comments •Top discharge with 1" threaded NPT connection provided. •Models up to 7 amps, single phase are available with 8-pin quick connect cable and standard on all "O/M Multi-Option" Systems. •Available in Duplex arrangementsDescription of Stancor Simplex Oil-Minder® SystemsThe Stancor Simplex Oil-Minder® System is available in two primary configurations, as follows: •The Multi-Option Oil-Minder® System is designed for easy fool-proof installation. All pump and control cables are factory wired into a wall mountable junction box. Between the junction box and the main Oil-Minder® control panel is a multi-pin quick connect cable. This single cord, 8-pin system allows the electrical cable between the junction box and control panel to be run through conduit and interconnected up to 250 feet long, using a single "push and turn" motion. There is no need for field wiring. Electrical installation costs are reduced by approximately 75% and all connections are secure and water-tight. •The Junior Oil-Minder® System is a good choice where the main control is located in the same area as the pump pit, or where the main control will be located remotely and conventional "hard wiring" is used between a junction box and the main control. Comparative features of each model are as follows:Features Included in O/M Multi-Option •Solid state NEMA 4x control panel •Separate LED indicator lights on NEMA 4x control for A) oil alert, B) high water, C) high motor amps, D) power to system, and E) pump activation •Self cleaning, hermetically sealed stainless steel oil detection probe •Float switches for pump activation and high water alert •Monitoring relays for alert conditions at remote locations •High decibel, water tight horn and silence switch for alert conditions •Direct plug-in activation of entire pump and control system from the main control panel (6' cord and molded plug included) •Factory hard wiring of pump, oil probe, and floats into NEMA 4x junction box •Junction box with female 8-pin cable receptacle and disonnect •25' 8-pin Quick Connect cable (expandable to 250' with interconnecting extension cables) •Female 8-pin cable receptacle installed in the NEMA 4x control panelFeatures Included in O/M Junior •Solid state NEMA 4x control panel •Separate LED indicator lights on NEMA 4x control for A) oil alert, B) high water, C) high motor amps, D) power to system, and E) pump activation •Self cleaning, hermetically sealed stainless steel oil detection probe •Float switches for pump activation and high water alert •Monitoring relays for alert conditions at remote locations •High decibel, water tight horn and silence switch for alert conditions •Direct plug-in activation of entire pump and control system from the main control panel (6' cord and molded plug included) •Factor hard wiring of pump, oil probe, and floats directly into main NEMA 4x control panelStancor Simplex Oil-Minder® ControlsTypical Stancor Simplex Multi-Option Oil-Minder® System •1. Stancor Model SE-40 submersible effluent pump .4 HP, 115 volt, 3600 RPM, 2" discharge connection (shown as example) •2. Check valve (2") •3. Stancor Oil-Minder 115V, 1? control system with built-in audible and visual alarm when pump does not run due to oil in pit or high liquid or high amperage condition. Provide silencing button for audible alarm built into panel. Panel shall have two contacts for a remote alarm location (one each for oil and high water or amperage alert). Junction box will be provided with multi-pin connector and cord in lengths as required, 25 ft. standard, optional 25 ft. increments. •4. Junction box will be provided with multi-pin connector and cord in lengths as required; 25 ft. is standard, optional 25 ft. increments available up to 250 ft. •5. All buried pump pressure discharge piping shall be protected with tapecoat CT corrosion protection tape •6. Pump cable, probe cable, high liquid alarm cable, and pump "on" float cable (16 ft. lengths) •7. High liquid alarm float with clamp device to mount to pump discharge piping •8. Pump On float •9. Power cord and molded ground plug (6 ft. length) for 115 V and 230 V single phase only under 2 hp Items 1, 3, 4, 6, 7, 8 and 9 provided by Stancor as a Standard Package.Direct Wire Elevator Oil-Minder® Systems •Stancor Model ________ submersible effluent pump ____HP, _____ volt, 3600 RPM, ___" discharge connection (shown as example) •Check valve (2") •Stancor Oil-Minder _____V, 3? control system with built-in audible and visual alarm when pump does not run due to oil in pit or high liquid or high amperage condition. Provide silencing button for audible alarm built into panel. Panel shall have two contacts for a remote alarm location (one each for oil and high water or amperage alert). •Junction box available as a factory option with or without a lockable pump disconnect switch •All buried pump pressure discharge piping shall be protected with tapecoat CT corrosion protection tape •Pump cable, probe cable, high liquid alarm cable, and pump "on" float cable (16 ft. lengths standard) •High liquid alarm float with clamp device to mount to pump discharge piping •Pump On float •Oil sensing probe •Items 1, 3, 6, 7, 8 and 9 provided by Stancor as a Standard PackageTypical Stancor Direct Wire Oil-Minder® SystemStancor Duplex Oil-Minder® SystemThe Stancor Duplex Oil-Minder® System provides for all the safety and operational features of the Simplex System, while allowing two pumps to operate together in the same sump. The Duplex Oil-Minder® Control alternates each pump upon start-up, assuring equal run time and wear. In the event of heavy inflow, both pumps will operate together until the water level recedes and both pumps are deactivated. The high level/lag pump float will activate an alarm if the water condition continues after a pre-set time point is reached (set for 6 seconds, adjustable between 6 seconds and 10 minutes). An alarm and separate diagnostic LED lights are provided for oil alert, high water, and high amperage (pump overload) conditions. Remote monitoring relays are also pro vided for alert conditions. A silence and reset switch clears the alarm mode once a fault is addressed. In addition, there are LED lights to "power" the system and to in dicate "pump 1" and "pump 2" activation. As with all Stancor Oil-Minder® Systems, oil is contained in the sump while water is pumped on a fully automatic basis, assur ing protection of the environment, personnel, and valuable equipment-even during an alarm condition. The standard Stancor Duplex Oil-Minder® System includes two SE-50 pumps (115v or 230v). However, Stancor can provide systems with any of its wide range of pumps up to 75 HP, with electrical provisions that meet the customer's requirements.Typical Stancor Duplex Oil-Minder® SystemStancor's Commitment to Quality and ReliabilityThousands of Stancor Oil-Minder® systems are used by environmentally conscious companies throughout the world. Major industrial, ccmmercial and non-profit institutions have discovered that the best way to protect valuable equipment, personnel and the environment is with the Stancor Oil-Minder® System. Applications include hydrocarbon sumps, elevator pits, washdown tanks, manufacturing facilities, transformer vaults and substations. Our commitment to quality and reliability is the same whether the application is the largest US Embassy in the world ( Beijing) or a small town utility co-op in rural South Dakota. As a leading designer and manufacturer of electric submersible pumps and controls, Stancor is qualified to provide both standard and customized systems to meet virtually any specification. Packaged systems, complete with heavy duty tanks, covers, and internal plumbing are available from our factory. Our engineering staff will help you design the right control and pump for special applications. Stancor pumps are available from 1/2 HP to 75 HP, so we always have the right equipment for the job.
