Super Precision Vertical Turret Milling Machine

US $10,500.00

Ontario, California, United States
Jan 30th

Open on mobile:
QR code

Super Precision accuracy, one of the best in this class knee type Turret milling machine, made in Taiwan Professional Machine Builder, with X and Y Align AL-500 Power feeds, Newall DP-700 2-Axis DRO installed.. 9” X 49” Table, Hardened & Ground Table with Ground T-Slot, Super precision Quality 3HP Spindle Motor, variable speed R8 Spindle Material Scm415(SAE4115) Hardened & Ground. Bearing support to the motor shaft Unique rigid design on spindle auto-feed, spline design on the pinion & clutch support Turcite-B On X&Y Ways, Slide-ways and Gibs. Hardened & Ground X&Y Slide-ways. Electroless Nickel-Phosphorus Process On X&Y lead-screw with hardness 35 HRC. Lead-screw nut made from PBC2, phosphor bronze Highly Improved Vari-Speed Head. 1-1/4”(32mm) Diameter Lifting Screw. Leveling Screw & Plate On Base. Strict standard of Scraping with High Precise Accuracy. Tool box & Tools Rubber chip cover (front & rear ) Specification: Table: 9” x 49” (230 x 1245mm) T-Slot No.x Size: 3” x 5/8” (3 x 15.875mm) Longitudinal travel (W/O power feed ): 37” (940mm) (With power feed ): 34”(863mm) Cross travel: 12” (305mm) Travel of knee: 16” (406mm) Ram travel: 14” (356mm) Quill travel: 5” (127mm) Table to spindle nose (D): 1-3/8” - 17-3/8” (34-440mm) Over swivel on turret: 360? Head Swivel ( R & L ): 90? Head tilt ( UP & DOWN ): 45? Spindle to column (F): 6”-21” (153-544mm) Spindle motor: 3HP Spindle taper: R8 (or NST#30 ) Quill feed: 0.0015” - 0.003” - 0.006” Spindle Speed (r.p.m.): ( 60Hz) 60-4500, ( 50Hz ) 50-3800 Overall height (A): 84” (2140mm) Overall depth (B): 63-5/8” (1618mm) Overall width (C): 59” (1497mm) Net Weight: 2200 lbs. (950 Kgs) ATMIUSA.COM Visit My eBay Store: atmi-usa Visit my eBay Store:atmi-usa

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	Taiwan
Model	SP-150VSL
Brand	Manford
