Tektronix 2430 150mhz Digital Oscilloscope; Refurbed Calibrated Guaranteed @bin

US $649.00

Antioch, California, United States
Jan 29th

Open on mobile:
QR code

TEK 2430 is a DSO from the repairable era (circa 1987, made same time as 2445A, 2465A, 2467) and cost over $6000 new. It is the predecessor of the 2430A (2430A has similar capabilities but added some convenience features such as auto-scaling and auto measure, 2430 has curser measurements). The predecessor of the the 2430 was the 468 (a combiscope relative of the 465B). Serial # is B012710. Will be shipped freshly calibrated, with 2430A (similar) instructions manual on a CD, cord, and 14 days guaranty. 1st photo shows a 1Vpp positive going 1KHz squarewave signal into CH1. 2nd photo shows it stores (cord is removed). 3rd photo shows that a signal can be stored just at the instant cord is removed. 4th photo shows same signal into CH2. 5th signal shows a 1KHz signal from a time mark generator. 6th photo shows self tests pass (doesn't prove everything is fine). 7th photo is of rear. 8th photo is of bottom. 9th photo is of left side. 10th photo is of right side. Photos were taken before refurb/cal. Before digital storage scopes evolved into small lunchbox sized surface mount populated fluff boxes in the late 90s, there were digitizing scopes such as the Tektronix 2430 that actually contained normal size parts that can be worked on with human sized fingers. So unlike with newer DSOs, this item does not become e-waste first time it breaks. Tek labels the 2430 as 150MHz / 100 Megasamples/second. Analog scopes should not be used close to their upper bandwidth limit, digitizing scopes carry the same caveat even more so... It is recommended for use at under 40MHz. Like all digital 24__ scopes, it is fulltime digitizing, meaning there is no analog fallback mode as 468 had. If you consider that a drawback, at least rejoice in that unlike in analog 24__, there is no possibility of the dreaded U400 or U800 IC failure. Whereas a non-storage scope can only display what happens after triggering, a digital storage scope can also display what happens before triggering, and this is its main advantage it's like a time machine. You can think of it as an endless loop recorder (like a cockpit voice recorder of an airplane) and you can look back any part of the loop you haven't re-recorded over. The length of the loop is 1024 recording points. A point can be as long as 50mS at the slowest sweep speed, or as short as 10nS at the faster sweep speeds. Similarly the vertical scale is 256 points. Ask questions (in English or French). It's a good way to discuss your exact needs, match you with correct package, options, accessories... even before you buy... I ship worldwide. Paypal requires I ship only to your Paypal address with tracking and delivery confirmation. International Airmail has poor tracking and no delivery confirmation, which is why it is not an option if you pay with Paypal. California buyers pay California sales tax (but I'll add something extra to try to make it up to you). HURRY INCENTIVE: if you BIN by Cyber Monday 1 Dec 14, I will ADD 1 TEK 10:1 PROBE (w/ R/O encoding), free; and upgrade your (US) shipping from ground to 2day Prio Airmail if ground would take longer than 2 days, FREE!

Condition	Seller refurbished : An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes	“refurbed & traceably calibrated by me at BUY IT NOW price. Li battery was replaced with a new one (doubt any other seller cares to do that for you).”
