Tektronix Awg2040 48-440 Hz Arbitrary Waveform Signal Generator W Options!

US $949.99

Broomfield, Colorado, United States
Jan 29th

Open on mobile:
QR code

Store Home Other Items Add to Favorites Join our Newsletter Contact Us Store search in titles & description Buy with Confidence Store Categories Computer Hardware MRO & Industrial Supply Medical Integrated Circuits & Misc Vintage Bulbs & Tubes Cameras & Acc. PLC & PCB Boards Consumer Electronics Industrial Electronics Telephone Vintage Electronics Vintage Lab & Science Hobby Electronic Components Amphenol/Attenuators Other Store Pages Store Home About Us Contact us Feedback Our Newsletter Make sure you get our updates on discounts and new available products ! Express Delivery Store search in titles & description Sony Tektronix AWG2040 48-440 Hz Arbitrary Waveform Generator TESTED GOOD! W OPT This unit came form a working test environment. it Includes options 010309. It was tested using the self test feature, and everything passed. If you're looking for other test equiptment, please check our other auctions. 1.024 GS/sec Clock Rate Provides up to 500 MHz Waveforms 1 MB Record Length (4 MB with Opt. 01) 8-Bit (1/256) Vertical Resolution Direct Waveform Transfers from DSO Optional 8-Bit Digital Pattern Generator Built-in 1.4 MB PC-compatible 3.5 in. Floppy Disk for Storage and Transfer FFT Editor (Opt. 09) Allows Editing in the Frequency Domain Easily Create Automatic Test Sequences with Waveform Sequencing Formula Entry of Parameters for Mathematically Precise Waveforms Fully Programmable from Front Panel, RS-232, or GPIB (IEEE 488.2) Characteristics Standard Waveshapes Sine, square, triangle, ramp, pulse, arbitrary, linked sequence, and DC. Arbitrary Waveforms Memory Waveform: 1 Mwords x 8-Bits (4 Mwords x 8-Bits with Option 01). Marker: 1 Mwords x 2-Bits (4 Mwords x 2-Bits with Option 01). Data Points of Waveform: 32 to 1 M ( 4 M with Option 01) in multiples of 32. Clock Generator Frequency Range: 1.000000 kHz to 1.024000 GHz. Resolution: 7 digits. Stability: 1 ppm/year (+15 to ± 25 degrees C). Operating Modes Continuous: Output waveform/sequence continuous at programmed waveshape, frequency, amplitude, and offset. Triggered: Output quiescent until triggered by an external, GPIB, or manual trigger; generates a waveform/sequence only one time. Burst: Output quiescent until triggered by an external, GPIB, or manual trigger; then generates a waveform/sequence up to 65,536 times. Gated: Same as continuous mode except period is executed only for the duration of the gated signal until the sequence started is completed. Waveform Advance: Output quiescent until triggered by an external, GPIB, or manual trigger, then generates the waveform/sequence in the Sequence file. When the scan count reaches value, output stops and waits for next trigger. Auto Step: Continuously outputs the waveform/sequence in the Auto Step file; the next Auto Step Trigger (rear panel) advances the waveform/sequence. Slave: Receives clock from a master arbitrary waveform generator for parallel operation. Main Output Digital-to-Analog Converter Resolution: 8-Bits. Output Impedance: 50 ohm Output Voltage: -2.0 V to +2.0 V into 50 ohm. Amplitude: Range: 20 mV to 2 V into 50 ohm. Resolution: 1 mV. Offset: Range: -1.000 V to 1.000 V into 50 ohm. Resolution: 1 mV. Accuracy (20 mV Amplitude, 7F waveform data): ± (1% of offset + 5 mV). Rise Time: Amplitude >1.0 V, 1.0 V, 1.0 V, within ± 10%. Amplitude Notice ATTENTION: What is pictured above is what to expect, unless stated otherwise in the title or description above. All used items are sold un-tested unless stated otherwise. The numbers at the end of the listing title, often in parenthesis, are our internal inventory code, please don't mind these numbers. Payment We accept payments of Credit Card, Debit Card, or E-checks through PayPal only. Please pay within 3 days or please contact us to arrange payment or to cancel the transaction.

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“ITEM WAS PULLED FROM WORKING ENVIRONMENT.”
