Tektronix Fg 501 Function Generator Plug-in, Works Great. Fully Functional

US $115.00

  • Seattle, Washington, United States
  • Jan 29th
Open on mobile:
QR code
TEKTRONIX FG 501 Function Generator SN: B127941 Photos are of the actual instrument you will receive and show it's overall good operating/physical condition. It is fully tested and verified in good working condition. This plug in works in a Tek. TM 501, TM503, TM 504, TM 506, and TM 5006 series Module power supply. The FG501 Function Generator outputs sine, square, triangular, pulse and ramp waveforms from 0.001 Hz to 1 MHz. It is intended for use in any of the TM-Series power supplies, such as the TM503. Frequency is adjusted by a decade switch for ranges and dial for X1 to X10. Frequency stability is better than 2% (a function of temperature). Frequency can also be controlled, over a 1000:1 range, by applying an external input to the VCF connector. Output amplitudes of 15 Vp-p open circuit and 7.5 V into 50-ohms can be obtained. Additional offsets of up to 5 V are accessible. Sinewave distortion is less than 1% and risetime is less than 100 nS on pulses. Triangle and ramp linearity is within 1%. Guarantee Terms: This item is guaranteed to power on & has no known functional Issues. If the item does not power on (DOA) or  is functionally defective, you may qualify for a refund. In such a case, you must contact me within 14 days after  you received it. Thanks for looking!
Condition Seller refurbished :
An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes “Fully function, verified, Calibrated, and adjusted to the best possible condition.”
