Tektronix Picosecond Pulse Labs 10,060a Pulse Generator 50ps 10v Step Tdr Emp

US $8,510.00

Santa Fe, New Mexico, United States
Mar 8th

Open on mobile:
QR code

Tektronix/Picosecond Pulse Labs 10,060A Pulse Generator This is a Tektronix/Picosecond Pulse Labs 10,060A pulse generator with user manual. The Model 10,060A produces 10 V pulses with 55 ps rise-time. Duration is adjustable from 100 ps to 10 ns. All of the pulse parameters, except rise/fall-times, are fully programmable via the GPIB interface. Slower rise-times can be obtained by externally attaching a rise-time filter. Impulses can be created by adding an Impulse Forming Network. Applications EMC (electromagnetic compatibility) testing EMI (electromagnetic interference) testing EMP (electromagnetic pulse) testing TDR (time domain reflectometry) testing TDT (time domain transmission) testing UWB (ultra wide band) equipment testing Features Rectangular waveform GPIB (IEEE-488) programmable User-friendly controls 10V, 45 ps rise-time pulse 100 ps to 10 ns pulse duration Low jitter, 1.5 ps RMS 81 dB variable attenuator (1 dB Steps) Click Here to Download Data Sheet Click Here to Download Application Note: Comparison of Ultra-fast Risetime Sampling Oscilloscopes Click Here to Download Application Note: Pulse Measurements in the Picosecond Domain Click Here to Download Application Note: UWB Signal Sources, Antennas & Propagation Click Here to Download Application Note: Low-Pass Rise-Time Filter for Time Domain Applications Click Here to Download Application Note: Picosecond Pulse Generators for UWB Radar Specifications Trigger Mode Internal, External, Manual or GPIB Repetition Rate 1 Hz to 100 kHz Computer Connection GPIB Amplitude Range 900 μV to 10 V Fall Time 115 picoseconds Delay Jitter 1.5 picoseconds Duration 100 picoseconds to 10 ns Trigger Output Delay 0 to 63 ns Rise Time 55 picoseconds Output Polarity Positive AC Power 100/115/230 V AC, 50/60 Hz Retail Price $34,400.00 Inspection by a Hofstra Group technician allows us to guarantee this hardware to perform to your satisfaction. This item carries a 7-day unconditional right of return and a 90-day warranty. In the unlikely event that you need to return it, we will arrange and pay for return shipping in addition to refunding the purchase price and original shipping. Please review our Sales Agreement for more information. Please note that export of this item is controlled for some countries. Export is possible, but may require a license. It is not guaranteed that a license will be granted by the BIS, in which case the sale will be canceled. Please enquire for details. _gsrx_vers_586 (GS 6.8 (586))
